Procom DGC-202 Series Operating Instructions Manual page 37

Digital Input 4 Monitoring time for programmable digital
Delay input. Digital inputs are explained above.
Digital Input 5 Monitoring time for programmable digital
Delay input. Digital inputs are explained above.
Digital Input 6 Monitoring time for programmable digital
Delay input. Digital inputs are explained above.
ChgALt Vol The minimum voltage for the charging
alternator for a healthy charging
alternator/V-Belt.
Chg Alt- Duration for which the above voltage
V Belt Delay should fall below the set limit for the
engine to be stopped on fault.
Hooter ON TimeDuration for which the hooter shall be
ON, if not externally reset, while
announcing a fault.
Crank ON Time Maximum crank time.
Crank GapTime The delay between two successive cranks.5
Crank Attempts The maximum number of cranks that
shall be attempted to start the Engine.
N
Solenoid ON The time for which stop solenoid will be
time kept active while stopping the engine.
Please note that in case of PULL to Start
mode this time should be reduced
(recommended 5 sec).
Priming Delay The duration at which the stop solenoid
to go in the fuel shut-off mode and
simultaneously shall start the cranking
command when the start command is
initiated.
5 1-100 Sec
5 1-100 Sec
5 1-100 Sec
Disabled Disabled*
5-30
Disabled Disabled*
1-30 Sec
30 1-100 Sec
5.0 1.0-20.0 Sec
1-200 Sec
3 1-10
22 1-100 Sec
Disabled 1.1-9.9 Sec
Disabled*
