Procom DGC-202 Series Operating Instructions Manual page 19

Apparent Power This icon shows the apparent power of Mains or Generator. When Mains
S
Power Factor
Total Power
Battery Voltage
Chg. Alt Voltage Charging Alternator Voltage.
Service due Hour Remaining hours for servicing the generator.
Run Hour
Energy
E
LLOP Sensor
HWT Sensor
Fuel Sensor
Oil Temperature
Sensor
RTC
12.0 Keys & LEDs Description
DGC202x has seven Keys provided on its front panel. The table below describes the operation of
these.
Keys Symbol Keys Function
Next
Increment
/Start
contactor is connected, it shows Mains apparent power. When generator
contactor is connected, it shows Generator apparent power.
This icon shows the power factor of Mains or Generator. When Mains
contactor is connected, it shows Mains power factor. When Generator
contactor is connected, it shows Generator power factor.
This icon shows the total power of Mains or Generator. When Mains
contactor is connected, it shows Mains total power. When Generator
contactor is connected, it shows Generator total power.
battery voltage.
Run Hour of generator.
KWhr of Genset
This icon shows the low lube oil pressure of generator.
This icon shows the high-water temperature of generator.
This icon shows the fuel of generator.
This icon shows the oil temperature of generator when CAN is enabled.
This icon shows the current date and time.
Description
Normal operation mode: It is used to scroll forward the
parameters being displayed on LCD.
Programming Mode: Key displays the next parameter to be
programmed.
Programming Mode: It is used to increment
the value of the parameters being modified.
Manual mode: it is used to issue the crank/ start command to
DG. Crank is disabled while in Programming Mode.
