Procom DGC-202 Series Operating Instructions Manual page 20

Decrement /StopProgramming mode: It is used to decrement the value of the
Reset
Programming
/History
Fault Mode Entry
MCB
GCB
MODE
M
LED Annunciations Description: DGC202X has 5 annunciations on its front panel. These either
announce the faults or indicate status of the system.
Nomenclature Symbol
Auto Auto
Manual Manual
Test Test
Fault Fault
Warning Warning
13.0. Lamp Test:
If the DGC202X is switched on while the reset switch is pressed, all the LEDs start blinking till
the reset switch is kept pressed. This state shall persist till the switch is kept pressed and on
release of the switch DGC202X shall start functioning normally.
14.0. Setting Procedure:
DGC202X has provision to program the operating parameters. It is user/site configurable. User
can view all parameters, fault history, events, adjust clock, reset password and also edit the
parameter.
parameter being modified program.
Manual mode: It is used to issue the stop command to DG. Stop
is disabled while in Programming Mode.
Normal Operation: Reset key resets the Hooter and Fault signals.
The first press shall reset the hooter and next shall reset the
faults. A long press of 1 Sec shall reset both.
Programming Mode: Go a level up.
If both the keys are pressed simultaneously, the unit will enter in
first Level of the Programming Mode. Here Edit/View of the
Parameters or View history, events and CAN status could be
selected.
Test Mode: Toggles then mains contactor, On/Off
Programming Mode: Scrolls the parameter back
Test Mode: Toggles then generator contactor, On/Off
Programming Mode: Scrolls the parameter forward
Toggle between Auto, Manual and Test Mode
Please refer to Digital Input section for more clarity
Description
Led lights up when unit is in Auto mode
Led lights up when unit is in manual mode
Led lights up when unit is in Test mode
This LED blinks in case of a fault
This LED blinks in case of a warning
