Procom DGC-202 Series Operating Instructions Manual page 26

Fuel
Sensor V9
Fuel
Sensor R10
Fuel
Sensor V10
HWT Select the installed sensor for HET
Sensor There are many built in sensors to choose from.
For sensors whose data is not in-built User
defined can be selected and the sensor data
programmed. Below twenty parameters are for
programming the User defined sensors. If a in-
built sensor is selected the following twenty
parameter shall not be displayed
HWT R1 to R10 = Resistance Value
Sensor R1 V1 to V10 = Corresponding temperature in °C.
These table are used when sensor type is
selected as user defined.
HWT
Sensor V1
HWT
Sensor R2
HWT
Sensor V2
HWT
Sensor R3
HWT
Sensor V3
HWT
Sensor R4
HWT
Sensor V4
HWT
Sensor R5
HWT
Sensor V5
HWT
Sensor R6
90 0-100
200 0-999
100 0-100
Type A User Defined
Type A
M&M
MNEPL
VE
TMTL RANGE 1
TMTL RANGE 2
TMTL WATER
HUAFANG
TATA
GC(VDO)
GC(MURPHY)
Disabled *
540 0-9999
40 0-300
458 0-9999
45 0-300
222 0-9999
65 0-300
120 0-9999
85 0-300
93 0-9999
90 0-300
80 0-9999
