Procom DGC-202 Series Operating Instructions Manual page 27

HWT
Sensor V6
HWT
Sensor R7
HWT
Sensor V7
HWT
Sensor R8
HWT
Sensor V8
HWT
Sensor R9
HWT
Sensor V9
HWT
Sensor R10
HWT
Sensor V10
Sensor Open User can select the action to be taken in case of
sensor open, it can be configured as a fault, or as
warning.
Fault selection shall shut down the engine.
Warning setting shall display a warning but will let
the engine continue.
No action will all together neglect the fault
Please note that a faulty sensor shall not protect
the engine till alternate provision such a sensor
switch is connected on a Digital Input.
CT Ratio Current Transformer ratio.
Gen. RPM Engine RPM Type.
User Contact This is a programmable output which can be
configured for any one function from the list.
Over The Power (KW) above which the over load fault
Load KW monitoring will start. The timer for it is over load
delay.
This fault is only enabled while the generator is
running. On expiry of the timer the generator is
stopped.
95 0-300
70 0-9999
100 0-300
60 0-9999
105 0-300
53 0-9999
110 0-300
46 0-9999
115 0-300
Warning Fault
Warning
None Action
1 1-1999
1500 1500RPM
3000RPM
None None
Heater /Choke
Fuel Pump
Load Warning
Unit Healthy
MCCB Shunt Trip
40 1-9999
