- Page 1 OPERATING INSTRUCTIONS SER-1P SER-IP V in Technical Guide...
- Page 2 INDEX • 1.0 Introduction • 2.0 Salient Features • 3.0 Display/Front Panel • 4.0 Technical Specification • 5.0 Relay Card Description: • 6.0 Switches Description • 7.0 LEDs Description • 8.0 Parameter Mode • 9.0 Setting Procedure: How to Enter in Parameter Mode •...
- Page 3 0 1.0 Introduction SER-1P is digital controller equipped with 3 row alphanumeric seven segment display and 5 navigator keys simplifies configuration of controller. 0 2.0 Salient Features: • 32 Bit RISC floating point microprocessor. • Response time 60mSec. • Fast Fourier Transformation to eliminate Harmonics & Surges/Sag.
- Page 4 Mounting : Panel Mount Cut out Dimensions : 91mm X 91mm 0 5.0 Relay Card Description: ! For SER-1P four potential free output contacts are provided : 1. Phase Increase 2. Phase Decrease 3. Hooter 4. Trip. ! Relay Specifications...
- Page 5 0 6.0 Switches Description: PSR-3/PSR-1 has 6 switches provided on its front panel. The table below describes the operation of these: Switch Symol Switch Function Description Manual Mode By pressing the Manual switch, for 3 sec controller enters in manual mode. Auto Mode By pressing the Auto switch for 3 sec , controller enters in Auto Mode.
- Page 6 0 7.0 LEDs Description SER-1P has 8 LEDs provided on its front panel. The table below describes the operation of these. Nomenclature Symbol Description Auto Auto LED glows continuously when controller is in Auto Mode. Manual Manual LED glows continuously when controller is in Manual Mode.
- Page 7 0 8. Parameter Mode The following tables gives the detailed descriptions of parameter name/settings Parameter Explanation of Parameter Factory Setting Name Setting Range on Display System settings are password Ent PAS (Enter 1-999 protected. Password is a three digit password) number.
- Page 8 0 9. Setting Procedure: How to Enter in Parameter Mode • Press AUTO & RESET switches simultaneously. The controller shall display, "Edt". • To enter in edit parameter mode Press Keys above Press Auto & Reset switch together Together & Edt appears on display.
- Page 9 CT PRI 005 Display will show CT PRI 005 Press INC or DEC switch to select the desired CT Primary turns .Press "Reset" switch to move forward CT SEC 005 Display will show CT SEC 005 Press INC or DEC switch to select the desired CT Secondary turns.
- Page 10 UV DLY 3 Display will show UV DLY 3 Press INC or DEC switch to select the desired Under voltage fault delay. Press "Reset" switch to move forward OL 005 Display will show OL 005 Press INC or DEC switch to select the desired Over Load limit.
- Page 11 0 10. Setting Procedure: How to Restore Factory Settings Press Keys above Press AUTO & RESET switch together Together Press INC switch to choose DEF SET Press "Reset" switch to move forward. Display will show DEF SET DEF SET Press "Reset" switch to move forward. Display will show Ent PAS 1 Ent PAS 1 Press INC/DEC switch to enter desired password...
- Page 12 0 11.0 Setting Procedure: How to Enter in View Mode Press Keys above Press AUTO & RESET switch together Together Press INC switch to choose VIE Press "Reset" switch to move foreward. Display will show VIE Press "Reset" switch to move forward. By pressing "Reset"...
- Page 13 0 13.0 Terminal Numbers: Terminal No. Description Voltage I/P Blank Neutral Voltage O/P CT S2 Blank CT S1 Motor UP Motor Down Hooter Trip Common for Triac Remote UP Remote Down Common Hig-Cut Low-Cut Blank Neutral...
- Page 14 0 14.0 Connection Diagram: Motor UP Voltage I/P Motor Down Blank Hooter Neutral Trip Com Triac Voltage O/P Remote UP Remote Down Common High Cut Low Cut CT S2 Blank Blank CT S1 Neutral...
- Page 15 0 15.0 Dimensional Detail All dimensions are in mm.
