Write Message Setup Example

Read/Write Message
Type: Peer-To-Peer
Read/Write: Write
Target Device: 500 CPU
Local/Remote: Local
Control Block: N11:0
Control Block Length: 14
Channel: 0
Target Node: 2 (002) (this is Quantum™ Panel ID)
Local File Address: N12:0
Target File Address/Offset: N55:3
Message Length in Elements: 1
Message Time-out (seconds): 15
(Refer to the "Allen-Bradley Programming Overview"
Section for more information)

PLC-5/30 - Suggested Setup

Channel 0 - 25-pin D-shell serial port; supports standard
EIA RS-232C and RS-423 and is RS-422A compatible.
NOTE: Channel 0 is optically-coupled (provides high
electrical noise immunity) and can be used with most
RS-422A equipment as long as:
•
termination resistors are not used
•
the distance and transmission rate are reduced to
comply with RS-423 requirements
The PLC-5's switch 2 is used to select RS-232C, RS-
422A, or RS-423. Channel 0 can be wired for RS-422.
Following is the pin connections showing how to wire the
PLC-5 channel 0 connector to the Quantum™ for RS-422
communication:
PLC-5 CH0
Pin 2 (TXD.OUT+)
Pin 3 (RXD.IN+)
Pin 14 (TXD.OUT-)
Pin 16 (RXD.IN-)
Channel 0 Setup:
Port
RS-232C
RS-422A
RS-423
Important guidelines:
•
When channel 0 is configured for RS-422A
compatibility, do not use terminating resistors
anywhere on the link.
•
When channel 0 is configured for RS-422A
(compatible) and RS-423, do not go beyond 61 m
(200 ft). This distance restriction is independent
from the transmission rate.
®
FRICK QUANTUM™ ACUair
COMMUNICATIONS SETUP
Quantum Com-2
Pin 1 (-RX)
Pin 3 (-TX)
Pin 2 (+RX)
Pin 4 (+TX)
Maximum Cable
length
15 m (50 ft)
61 m (200 ft)
61 m (200 ft)
®
CONTROL PANEL

Channel Configuration

Channel 0 = System (Leader) for half-duplex or System
(Point-To-Point) for full-duplex
Remote Mode Change: DISABLED
Mode attention Char: \0x1b
System mode char: S
User mode char: U
Baud rate: 19200 (suggested)
Stop bits: 1
Parity: None
Station address: 5 (this devices ID#)
Control line: No Handshaking
Reply Msg Wait (20ms):
ACK timeout (20ms):
DF1 retries: 3
Msg appl timeout(30 secs):2
Error detect: BCC / CRC
RTS send delay (20ms): 0
RTS off delay (20ms): 0
Polling mode: Message Based (Do Not Allow Follower
to
initiate messages)
Leader Message Transmit: Between Station Polls
System (Point-To-Point) additional setup:
Duplicate Detect: OFF
NAK Receive:0
DF1 ENQS:0
(Refer to the "Allen-Bradley Programming Overview"
Section for more information)
PLC-5 Series and Firmware that support SL C500
commands
Model
5/30
5/40
5/60

Read Message Setup Example

Instruction Entry for Message Block MG14:0:
Communication Command: SLC Typed Logical Read
PLC-5 Data Table Address: N9:3
Size in Elements: 20
Local/Remote: Local
Local Node Address: 004 (Quantum™ Panel's ID)
Destination Data Table Address: N10:1
Port Number: 0
(Refer to the "Allen-Bradley Programming Overview"
Section for more information)
Series Firmware must
be at least:
C L
D C
A M
B J
C G
A M
B J
C G
E B
