Frick QUANTUM ACUair Setup page 11

RETURN Unit Status - Units1-4 data: $01IA
$ Start of command sequence.
01 Quantum ID code.
I(A-D) Unit Status Command
Unit 1=A; Unit 2=B; Unit 3=C; Unit 4=D
CS Checksum
CR Carriage Return
RETURNED ANSWER,
A Acknowledge
01 Quantum ID code.
I(A-D) Unit Status Command
F Digital Input Channels 1-4 (right to left)
Bit 0 - Air Flow Switch (1)
Bit 1 - Remote Process/Cleanup (2)
Bit 2 - Remote Start/Stop (3)
Bit 3 - Burner Status (4)
F Digital Input Channels 5-8 (right to left)
Bit 0 - Flame Failure (5)
Bit 1 - Aux #1 (6)
Bit 2 - Aux #2 (7)
Bit 3 - Aux #3 (8)
F Digital Output Channels 1-4 (right to left)
Bit 0 - Supply Fan Motor (1)
Bit 1 - Exhaust Fan #1 (2)
Bit 2 - Exhaust Fan #2 (3)
Bit 3 - Burner Command (4)
F Digital Output Channels 5-8 (right to left)
Bit 0 - Cooling Stage #1 (5)
Bit 1 - Cooling Stage #2 (6)
Bit 2 - Spare (7)
Bit 3 - Spare (8)
F Digital Output Channels 9-12 (right to left)
Bit 0 - Alarm (9),
Bit 2 - Spare (11), Bit 3 - Spare (12)
F Digital Output Channels 13-16 (right to left)
Bit 0 - Spare (13), Bit 1 - Spare (14)
Bit 2 - Spare (15), Bit 3 - Cleanup (16)
000 Analog Output 1- Outside/Return Air Dampers
000 Analog Output 2- Exhaust Command
000 Analog Output 3- Burner Output
000 Analog Output 4- Heat Profile
+000 Analog Input 1 - Outside Air Temperature
+000 Analog Input 2 - Discharge Air Temp.
+000 Analog Input 3 - Room/Return Air Temp
+000 Analog Input 4 - Spare Temperature
000 Analog Input 5 - Damper Position
000 Analog Input 6 - Exhaust Fan 1 Position
000 Analog Input 7 - Exhaust Fan 2 Position
00000 Analog Input 8 - Ammonia Detector
000 Analog Input 9 - Humidity
+000 Analog Input 10 - Room Pressure Sensor
+000 Analog Input 11 - Pre-Heat Air Temperature
0 Unit Status: 0-Off; 1-Running; 2-Starting
0 Unit Air Handling Mode:0-Process; 1-Cleanup
0 Unit Control Mode: 0-Local; 1-Remote
0 Control Value: 0-None; 1-Return Air; etc.
0 Control Setpoint: 0-None; 1-Process; etc.
0 Alarm: 0-None; 1-Alarm; 2-Shutdown
CS Checksum
CR Carriage Return
®
FRICK QUANTUM™ ACUair
COMMUNICATIONS SETUP
Bit 1 - Spare (10)
®
CONTROL PANEL
RETURN Unit Status - Units1-4 data: $01Z1
$ Start of command sequence.
01 Quantum ID code.
Z (1-4) Unit Status Command
Unit 1=1; Units 1,2=2; Unit 1-3=3; Unit 1-4=4
CS Checksum
CR Carriage Return
RETURNED ANSWER,
A Acknowledge
01 Quantum ID code.
Z(1-4) Unit Status Command
F Digital Input Channels 1-4 (right to left)
Bit 0 - Air Flow Switch (1)
Bit 1 - Remote Process/Cleanup (2)
Bit 2 - Remote Start/Stop (3)
Bit 3 - Burner Status (4)
F Digital Input Channels 5-8 (right to left)
Bit 0 - Flame Failure (5)
Bit 1 - Aux #1 (6)
Bit 2 - Aux #2 (7)
Bit 3 - Aux #3 (8)
F Digital Output Channels 1-4 (right to left)
Bit 0 - Supply Fan Motor (1)
Bit 1 - Exhaust Fan #1 (2)
Bit 2 - Exhaust Fan #2 (3)
Bit 3 - Burner Command (4)
F Digital Output Channels 5-8 (right to left)
Bit 0 - Cooling Stage #1 (5)
Bit 1 - Cooling Stage #2 (6)
Bit 2 - Spare (7)
Bit 3 - Spare (8)
F Digital Output Channels 9-12 (right to left)
Bit 0 - Alarm (9), Bit 1 - Spare (10)
Bit 2 - Spare (11), Bit 3 - Spare (12)
F Digital Output Channels 13-16 (right to left)
Bit 0 - Spare (13), Bit 1 - Spare (14)
Bit 2 - Spare (15), Bit 3 - Cleanup (16)
000 Analog Output 1- Outside/Return Air Dampers
000 Analog Output 2- Exhaust Command
000 Analog Output 3- Burner Output
000 Analog Output 4- Heat Profile
+000 Analog Input 1 - Outside Air Temperature
+000 Analog Input 2 - Discharge Air Temp.
+000 Analog Input 3 - Room/Return Air Temp
+000 Analog Input 4 - Spare Temperature
000 Analog Input 5 - Damper Position
000 Analog Input 6 - Exhaust Fan 1 Position
000 Analog Input 7 - Exhaust Fan 2 Position
00000 Analog Input 8 - Ammonia Detector
000 Analog Input 9 - Humidity
+000 Analog Input 10 - Room Pressure Sensor
+000 Analog Input 11 - Pre-Heat Air Temp.
0 Unit Status: 0-Off; 1-Running; 2-Starting
0 Unit Air Handling Mode:0-Process; 1-Cleanup
0 Unit Control Mode: 0-Local; 1-Remote
0 Control Value: 0-None; 1-Return Air; etc.
0 Control Setpoint: 0-None; 1-Process; etc.
0 Alarm: 0-None; 1-Alarm; 2-Shutdown
... *********
Above Data repeated for Units 2, 3, 4
CS Checksum
CR Carriage Return
S90-500 CS
