Technical Specifications - Omcan BE-IT-710-CSS Instruction Manual

Technical Specifications

Model
Electrical
Power
Cylinder Length
Cylinder Diameter
Sheeting Thickness
Table Length
Working Dimensions
Closed Dimensions
Packaging Dimensions
Weight
Packaging Weight
Item Number
Installation
PRECAUTIONS REGARDING THE PLACE OF INSTALLATION
The place in which the machine is to be kept and/or used must be compliant with the laws in force and
guarantee adequate protection from impacts, damage, and deterioration and from atmospheric agents. The
access routes must have adequate dimensions and characteristics for letting the machine pass easily, without
risks of harm to people and to the machine itself. The characteristics of the flooring, bearing structures and
walls must be compliant with the laws and regulations in force, also considering the total load to support and
the relevant safety coefficients; the floors and walls of the room must be easy to clean and, where necessary,
to disinfect. The surface must be flat and compact without slopes, holes or asperities. The wiring system and
the equipotential protection system (ground) of the site must be compliant with the laws and regulations in
force; they must be made, maintained and, if envisaged by law, inspected by authorised and professionally
qualified technicians who are able to issue the envisaged declaration of conformity if required. Appropriate
devices for protection from overloads, short circuits, and phase-phase, phase-neutral (if pertinent) and phase-
ground currents must be fitted in the power board upstream.
TRANSPORT, HANDLING AND POSITIONING
Depending on the destination and contractual agreements, the machine is shipped wrapped in heat-shrink
plastic, resting and blocked on a pallet, or in a wooden crate, or in a wrapping of thick cardboard blocked
on a pallet with straps. The machines are shipped assembled (apart from the various accessories which, in
BE-IT-710-CSS
220V / 60Hz / 1
0 - 1.4" / 0 - 35mm
70.8" x 34.6" x 25"
1800 x 880 x 640mm
20.5" x 34.6" x 32.7"
520 x 880 x 830mm
36.2" x 24.8" x 40.2"
920 x 630 x 1020mm
253.5 lbs. / 115 kgs.
284.4 lbs. / 129 kgs.
49115
8
BE-IT-710-FSS
0.75 kW
19.7" / 500mm
2.4" / 60mm
28" / 710mm
70.8" x 34.6" x 43.3"
1800 x 880 x 1100mm
23.6" x 34.6" x 57.5"
600 x 880 x 1460mm
36.2" x 24.8" x 63.8"
920 x 630 x 1620mm
326.3 lbs. / 148 kgs.
359.4 lbs. / 163 kgs.
49116
