Omcan BE-IT-710-CSS Instruction Manual page 23

Model BE-IT-710-FSS
Item No. Description
Extension for Waste Collection Tray
AK612
for 49116
AK613 Waste Collection Tray for 49116
AK614 Conveyor Belt for 49116
AK615 Table for 49116
AK616 Waste Collection Drawer for 49116
AK617 Belt Stretcher Cylinder for 49116
AK618 Rolling Pin Fork for 49116
AK619 Spacer for 49116
AK620 Tray Locking Handwheel for 49116
AK621 Support for Tables for 49116
Item No. Description
AK640 RH Shoulder for 49116
AK641 LH Shoulder for 49116
AK642 RH Panel for 49116
AK643 LH Panel for 49116
AK644 Flange for 49116
AK645 Bearing 6004 2RS for 49116
AK646 Seeger Ring for 49116
AK647 Spacer for 49116
AK648 Free Wheel Z=16 1/2" x 1/8" for 49116
AK649 Threaded Pinion for 49116
AK650 Double-Threaded Screws for 49116
Double Crown Wheel Z=16 1/2" x 1/8"
AK651
for 49116
AK652 Washer for 49116
AK653 Spacer for 49116
AK654 Gasket for 49116
AK655 Bolt for 49116
AK656 Lifting Rod for 49116
AK657 Cylinder Displacement Lever for 49116
AK658 Guard Rod for 49116
AK659 Bushing for 49116
AK660 Eccentric Bushing for 49116
AK661 RH Connecting Rod for 49116
49116
Position Item No. Description
1 AK622 Power Board Cover for 49116
2 AK623 Power Board for 49116
3 AK624 Frame for 49116
4 AK625 Adjustable Foot for 49116
5 AK626 Foot Adjustment Handwheel for 49116
6 AK627 Wheel for 49116
7 AK628 Screw for Wheel for 49116
8 AK629 Tie-Rod for Belt for 49116
9 AK630 Motor Support for 49116
10 AK631 Electric Motor for 49116
Position Item No. Description
1 AK662 Top Scraper Support Shaft for 49116
2 AK663 Top Scraper for 49116
3 AK664 Lifting Shaft Cover for 49116
4 AK665 Spacer for 49116
5 AK666 Tray Support for 49116
6 AK667 Guard for 49116
7 AK668 Fixed Cylinder for 49116
8 AK669 Bottom Scraper for 49116
Bottom Scraper Tensioning Spring for
9 AK670
49116
10 AK671 Scraper Positioning Section for 49116
11 AK672 Spacer for 49116
12 AK673 Pinion Z=16 3/8" for 49116
13 AK674 V Belt A 57 for 49116
14 AK675 Pulley for 49116
15 AK676 LH Connecting Rod for 49116
16 AK677 Shaft for Lifting for 49116
Displacement Rod for Connecting Rod
17 AK678
for 49116
18 AK679 Bushing for 49116
19 AK680 Handle Return Spring for 49116
20 AK681 Seeger Ring for 49116
20b AK682 Bearing 6005 2RS for 49116
21 AK683 Chain-Stretcher Crown Wheel for 49116
Parts Breakdown
Position Item No.
11 AK632
12 AK633
13 AK634
14 AK635
15 AK636
16 AK637
17 AK638
18 AK639
19
20
Position Item No.
22 AK684
23 AK685
24 AK686
25 AK687
26 AK688
27 AK689
28 AK690
29 AK691
30 AK692
31 AK693
32 AK694
33 AK695
34 AK696
35 AK697
36 AK698
38 AK699
39 AK700
40 AK701
41 AK702
42 AK703
43 AK704
44
23
Base Assembly
Description Position
Motor Pivoting Pin for 49116 21
Rear Side Closing Panel for 49116 23
Pedal for 49116 24
Lever for Pedal for 49116 25
Pedal Movement Inversion Microswitch
26
for 49116
Table Pivoting Rod for 49116 27
Pedal Control Guard for 49116 28
Front Side Closing Panel for 49116 29
Head Assembly
Description Position
Tie-Rod for Chain for 49116 45
Shaft Bushing for Lifting for 49116 46
Spacer for 49116 47
Guard Closure Microswitch for 49116 48
Spring for 49116 49
Microswitch Plate for 49116 50
Manual Movement Inversion Microswitch
51
for 49116
Lever Stop for 49116 52
Handwheel for 49116 53
Toothed Sector for 49116 54
Handle for 49116 55
Lever for Handle for 49116 56
Spring for 49116 57
Microswitch Spacer for 49116 58
Manual Motion Inversion Control Rod
59
for 49116
Knob for Manual Control Rod for 49116 60
RH Belt Drove Cylinder for 49116 61
LH Belt Drove Cylinder for 49116 62
Mobile Cylinder for 49116 63
Idle Crown Wheel Z=16 3/8 for 49116 64
Lever Stop Sector for 49116 65
