Technical Specifications - Omcan IC-CN-0050 Instruction Manual

Technical Specifications

Model
Hopper Capacity
Ice Shaving Capacity
Electrical
Power
Rotate Speed
Rotary Component
Dimensions
Packaging Dimensions
Item Number
Operation
1. Open the lid of the hopper, clean the hopper with dry cloth, check whether the blade is installed firmly.
2. Check the condition of the power cord and plug.
3. Open the lid, put the right amount of the ice cubes into the hopper, then cover it.
4. Through the knob to adjust the blade to shave the ice cube into small pieces or a little bigger pieces.
5. The ice cube must between 3-5cm.
6. There is a safety switch inside, which meant the machine won't be work with a open cover.
NOTE: Rotate the knob counterclockwise to the end before switch on the machine
NOTES
1. The machine must be used indoor.
2. Don't use the machine for other than intended or specified purposes.
3. To avoid electrical shock, don't place the cord or machine in water or other liquids.
4. Don't operate the machine with wet hands or operate in a wet working environment.
5. Keep the machine and power cable away from heat sources and hot surfaces.
6. The machine is not intended for use by persons (including children) with reduced physical, sensory or
mental capabilities, or lack of experience or knowledge, unless they have been given supervision or
instruction concerning use of the machine by a person responsible for their safety.
7. Don't fill the hopper above its maximum indicated level.
8. Don't place hands or any other items into the hopper while working.
9. Take extreme care and use appropriate tools when emptying or cleaning the hopper as the blade is very
sharp. Don't touch the blade with your hands.
IC-CN-0050
16.9 lbs. / 1.5 kgs.
264.6 lbs. / 120 kgs. per hour
110V / 60Hz / 1
0.33 HP / 250 W
320 RPM
Aluminum Alloy
1.4" x 15.4" x 16.9"
290 x 390 x 430mm
17.7" x 13.1" x 18.9"
450 x 334 x 480mm
47467
6
