Omcan BE-IT-710-CSS Instruction Manual page 20

Parts Breakdown
Model BE-IT-710-CSS
Item No. Description
AK528 Left Hand Frame for 49115
AK529 Right Hand Frame for 49115
AK530 Left Hand Panel for 49115
AK531 Right Hand Panel for 49115
AK532 Flange for 49115
AK533 Bearing 6004 2RS for 49115
AK534 Seeger Ring for 49115
AK535 Spacer for 49115
AK536 Freewheel Z=18 1/2" x 1/8" for 49115
AK537 Threaded Pinion for 49115
AK538 Double Screw for 49115
AK539 Double Crown Z=16 3/8 for 49115
AK540 Double Crown Z=16 3/8" for 49115
AK541 Spacer for 49115
AK542 Spacer for 49115
AK543 Limit Switch Sector Lever for 49115
AK544 Limit Switch Lever for 49115
AK545 Handwheel for 49115
AK546 Washer for 49115
AK547 Toothed Sector for 49115
AK548 Handle for 49115
Manual Movement Reverse Microswitch
AK549
for 49115
AK550 Microswitch Plate for 49115
AK551 Spring for 49115
AK552 Bushing for Connecting Rod for 49115
AK553 Guard Lifting Shaft for 49115
AK554 Cylinder Movement Lever for 49115
AK555 Grid Closing Microswitch for 49115
49115
Position Item No. Description
1 AK556 Grid Rod for 49115
2 AK557 Bushing for 49115
3 AK558 Right Hand Connecting Rod for 49115
4 AK559 Upper Scraper Shaft Holder for 49115
5 AK560 Upper Scraper for 49115
6 AK561 Lifting Shaft Protection for 49115
7 AK562 Spacer for 49115
8 AK563 Bowl Support for 49115
9 AK564 Protection Grid for 49115
10 AK565 Microswitch Spacer for 49115
Manual Movement Reverse Control Rod
11 AK566
for 49115
12 AK567 Manual Control Knob for 49115
13 AK568 L.H. Belt Drive Cylinder for 49115
14 AK569 Fixed Cylinder for 49115
15 AK570 R.H. Belt Drive Cylinder for 49115
16 AK571 Mobile Cylinder for 49115
17 AK572 Lower Scraper for 49115
18 AK573 Lower Scraper Tension Spring for 49115
19 AK574 Scraper Location Sector for 49115
20 AK575 Spacer for 49115
21 AK576 Sprocket Z=16 3/8" for 49115
22 AK577 A57 V Belt for 49115
23 AK578 Pulley for 49115
24 AK579 L.H. Connecting Rod for 49115
25 AK580 Spacer for 49115
26 AK581 Lifting Shaft for 49115
Connecting Rod Movement Rod for
27 AK582
49115
28 AK583 Bolt for 49115
Position Item No.
29 AK584
30 AK585
31 AK586
32 AK587
33 AK588
34 AK589
35 AK590
36 AK591
37 AK592
38 AK593
39 AK594
40 AK595
41 AK596
42 AK597
43 AK598
44 AK599
45 AK600
46 AK601
47 AK602
48 AK603
49 AK604
50 AK605
51 AK606
52 AK607
53 AK608
54 AK609
55 AK610
56 AK611
20
Description Position
Handle Spring for 49115 57
Seeger Ring for 49115 58
Bearing 6005 2RS for 49115 59
Chain Tightening Crown for 49115 60
Chain Rod for 49115 61
Chain Spacer and Rod for 49115 62
Lifting Shaft Bushing for 49115 63
Motor Pulley for 49115 64
Motor for 49115 65
Table for 49115 66
Belt Rod for 49115 67
Bearing 6001 2RS for 49115 68
Belt Stretching Cylinder for 49115 69
Conveyor Belt for 49115 70
Undertable for 49115 71
Undertable Extension Piece for 49115 72
Table Fulcrum Rod for 49115 73
Undertable Locking Handwheel for
74
49115
Hooking Spacer for 49115 75
Support Hook for Tables for 49115 76
Rolling Pin Hook for 49115 77
Belt Stretching Shaft for 49115 78
Electric Wiring Panel for 49115 79
Base for 49115 80
Main Switch for 49115 81
Start Button for 49115 82
Stop Button for 49115 83
Table Support for 49115 84
