belts supplied or, in any case, approved by the manufacturer. Both operations must be performed with the feet
resting on the ground and the machine blocked. Before any operation put on at least protective footwear with
reinforced toecap and work gloves with good resistance to abrasion.
CHANGING THE SCRAPERS
The scrapers must be replaced when they no longer ensure effective removal of the residues of dough, flour,
etc., across the complete length of the respective sheeting rollers.
TOP SHEETING ROLLER SCRAPERS
There are two scrapers mounted on a single angular metallic support. If spare scrapers are requested, the
manufacturer will supply the complete support + scraper assembly already mounted. Keep both safety guards
located at the sides of the sheeting rollers raised, for example by fixing them reciprocally in the raised position
with a double hook, stainless steel wire, etc. and then:
TO DISASSEMBLE THE SCRAPER ASSEMBLY
• Remove the three butterfly head screws.
• Grip the steel support and pull it upwards and then remove it.
TO MOUNT THE SCRAPER ASSEMBLY
• Position the scraper assembly above the roller and press it downwards in such a way that the plastic
scrapers slot into the sides of the roller itself.
• Align the holes and thoroughly screw in the screws.
BOTTOM SHEETING ROLLER SCRAPERS
There are two scrapers, reciprocally independent and positioned between the bottom sheeting roller and the
belts:
TO DISASSEMBLE THE SCRAPER ASSEMBLY
• Pass an arm under the worktable and with the hand detach the springs from the shank of the screws (there
are two springs for each scraper, one on each side).
• From below the worktable press the scraper assembly upwards with one hand and extract it from above
along with the arms and springs.
TO MOUNT THE SCRAPER ASSEMBLY
• Lower the scraper assembly from above in such a way that the arms with the springs drop and descend
vertically into the space between the roller of the belt and the bottom sheeting roller on which the scraper
will stop and rest; the arms with the springs will protrude under the worktable.
• From below the worktable, grip each spring and couple it to the screw, taking care to make the little pin
enter the slot in the arm.
