SHANGHAI SIMCOM LIMITED

6 RF Specification

_______________________________________________________________________________
6.1 R&D parameters
All measurements are taken at module RF I/O pins (pin 31 for BT/WIFI and RF connector for 5G_WIFI) with
IQ2015. All typical performance specifications are based on operation at room temperature (+25°C) using default
parameter settings and nominal supply voltages, such as VBAT = 3.8V.
6.1.1 SIMT1502's BT&WIFI
I (For CE)
Table6-1 BT&WIF
Item specifications
BT TX Power<10dBm
BLE TX Power<5dBm
WIFI TX Power<22dBm
The sensitivity of 5G WiFi CH36 have separate standards as follow Table6-2 CH36.
Table6-2 CH36
6 M
<-83dB
802.11a
54M
<-68dB
MCS0-HT20
<-83dB
MCS7-HT20
<-66dB
802.11n
MCS0-HT40
<-83dB
MCS7-HT40
<-64dB

6.1.2 SIMT1502 WiFi bands and bandwidth

The SIMT1502 WiFi bands and bandwidth is specified by Table6-3 and Table6-4.
2.4GHz WiFi only support 20MHz channels bandwidth.
5GHz WiFi can support both 20MHz and 40MHz channels bandwidth.
Table6-3 2.4G WiFi channels
Channel Frequency(MHz)
CHAN1 2412
