SHANGHAI SIMCOM LIMITED

4.12.2 I2C

SIMT1502 contains two groups special functional and four groups configurable I2C, which
multiplexed with UART function. I2C pins use GPIOs configured as open-drain outputs; the
pull-up resistor(2.2K) must be provided by external circuit(1.8V).
High speed mode I2C running at 3.4 MHz.
See Table4-12
Table4-12 I2C interface description
Signal Pin#
TS_I2C_SDA
TS_I2C_SCL
CCI_I2C_SDA
CCI_I2C_SCL
The rest of I2C interface is multiplexed with UART function.
See Table4-13 for more details.
Table4-13 I2C interface alternate function description
Signal Pin#
GPIO_6 24
GPIO_7 25
GPIO_111 28
GPIO_112 29
GPIO_14 22
GPIO_15 23
GPIO_10 110
GPIO_11 111

4.12.2 SPI

SIMT1502 contains three groups configurable SPI, which multiplexed with UART/I2C function.
But, SIMT1502 only be used for master device.
See Table4-14
Table4-14 SPI interface alternate function description
Description
34 Touchscreen/ SENSORS I2C,SDA
35 Touchscreen/ SENSORS I2C,SCL
63 Camera I2C,SDA
64 Camera I2C,SCL
UART2 CTS_N/GP
UART2 RTS_N/GP
UART2 CTS_N/GP
UART2 RTS_N/GP
SPI4 CS_N/GP
SPI4 CLK/GP
SPI6 CS_N/GP
SPI6 CLK/GP
Alternate function
BLSP#1_I2C_SDA_B
BLSP#1_I2C_SCL_B
BLSP#2_I2C_SDA_B
BLSP#2_I2C_SCL_B
BLSP4#_I2C_SDA_B
BLSP4#_I2C_SCL_B
BLSP6#_I2C_SDA_B
BLSP6#_I2C_SCL_B
Direction
AI/AO
B
DO
B
DO
28
