MIC_P/ MIC_N
USB-DM/USB-DP
PWRKEY

5.8 RF SPECIFICATION

5.8.1 Conducted Transmission Power

The following table shows the module conducted output power, and it follows the 3GPP TS 05.05 &3GPP TS
34.121 technical specification requirement.
Table 27: SIM5300E Conducted RF Output Power
Frequency
E-GSM900
DCS1800
WCDMA 2100
WCDMA 900
For the module's output power, please note:
At GSM900 band, the module is a class 4 device, so the module's output power should not exceed 33dBm on
the maximum power level. At the same time, the output power tolerance should not exceed +/-2dB under
normal condition and +/-2.5dB under extreme condition.
At DCS1800 band, the module is a class 1 device, so the module's output power should not exceed 30dBm
on the maximum power level. At the same time, the output power tolerance should not exceed +/-2dB
under normal condition and +/-2.5dB under extreme condition.
At WCDMA band, the module is a class 3 device, so the module's output power should not exceed 24dBm on
the maximum power level, and the output power tolerance should not exceed +1/-3dB.

5.8.2 Module RF Receive Sensitivity

SIM5300E_Hardware_Design_V1.02
±4KV
±4KV
Max
33dBm ±2dB
30dBm ±2dB
24dBm+1/-3dB
24dBm+1/-3dB
±8KV
±8KV
Min
5dBm±5dB
0dBm±5dB
-56dBm ±5dB
-56dBm ±5dB
