SHANGHAI SIMCOM LIMITED
Table4-4 Audio interface description
Signal Pin#
MIC3_IN 9
MIC2_IN 10
HS_DET 11
SPKR_DRV_M 12
SPKR_DRV_P 13
EARO_M 14
EARO_P 15
MIC_GND 16
MIC1_IN 17
MIC_BIAS 18
HPH_R 19
HPH_REF 20
HPH_L 21
Figure4-2 Audio application diagram

4.5 Camera interface

SIMT1502 contains two camera interface. Primary camera interface use 2-lane MIPI_CSI0,
supports CMOS and CCD sensors, up to 8MP sensors. Secondary camera interface use 1-lane
MIPI_CSI1, and 1.5Gbps per lane. Both are controlled by I2C bus.
See Table4-5 and Figure4-3for more details.
Table4-5 Camera interface description
Signal
SCAM_RST_N
SCAM_MCLK1
MIPI_CSI1_LN0_P
MIPI_CSI1_LN0_N
Description
Microphone 3 input, single-ended
Microphone 2 input, single-ended
Headset detection
Speaker driver output, minus
Speaker driver output, plus
Earpiece amplifier output, differential minus
Earpiece amplifier output, differential plus
GND
Microphone 1 input, single-ended
Microphone bias output voltage
Headphone right output
Headphone driver amplifier ground reference
Headphone left output
Pin# Description
3 Camera0 (front camera) reset
4 Camera0 master clock 1
5 MIPI camera serial interface 1 lane 0 – positive
6 MIPI camera serial interface 1 lane 0 – negative
Direction
AI/AO
AI
AI
AI
AO
AO
AO
AO
GND
AI
AO
AO
AI
AO
Direction
AI/AO
DO
DO
AI,AO
AI, AO
22
