PACE Pressure Controller User Manual
Example Program
Note: Changes to instrument settings made in a test program remain valid only for the test program.
The instrument reverts to the pre-test settings on completion.
Step Command
START
1 UNITS
2 RATE
3 IN LIMITS TIME
4 IN LIMITS
5 RESOLUTION
6 SETTLING
7 TEXT
8 ZERO
9 SET-POINT
10 CONTROL
11 WAIT IN LIMITS
12 BEEP
13 MEASURE
14 DWELL
15 SET-POINT
16 CONTROL
17 WAIT IN LIMITS
18 BEEP ON
19 MEASURE
20 TEXT
21 DWELL
22 BEEP
23 TEXT
24 PAUSE
25 VENT
END
K0443 Issue No. 3
Argument Action
Program start
mbar Select units, mbar
100 Select rate, 100 mbar/min
10 (00:00:10) secs
Set In Limits Band
5 Display resolution, 5 digits
No overshoot
Operator instruction, e.g."Connect UUT"
400 Set-point, 400 mbar
Controller ON
Wait for In Limits Condition
Beep on, approx. 1 sec, Beep off
Switch to Measure (controller off)
30 Wait for 30 sec (00:00:30)
800 Set-point, 800 mbar
Controller on
Wait for In Limits Condition
Beep on, approx. 1sec, Beep off
Switch to Measure (controller off)
Operator instruction,
e.g. (Wait for beep, record pressure)
30 Wait for 30 sec
Beep on, approx. 1 sec, Beep off
Operator instruction,
e.g. "Min pressure allowed 785 mbar"
WAIT, (for operator input to touch single step)
Vent
Program end
6 - 19
