Techni Mobili RTA-S06 Assembly Instruction Manual

Multi-functional computer table
Hide thumbs Also See for RTA-S06:

Advertisement

Quick Links

Download this manual
English
English
MULTI-FUNCTIONAL COMPUTER TABLE
MULTI-FUNCTIONAL COMPUTER TABLE
MODEL RTA - S06
MODEL RTA - S06
Thanks for purchasing one of our products, please read carefully the assembly
Thanks for purchasing one of our products, please read carefully the assembly
instructions before the installation (Attention: Do not tighten the screws before
instructions before the installation (Attention: Do not tighten the screws before
all screws are in place).
all screws are in place).
B15 090521
ASSEMBLY INSTRUCTION
ASSEMBLY INSTRUCTION
IMPORTANT:
IMPORTANT:
solution of a smooth soap and water, then cleared
solution of a smooth soap and water, then cleared
with a dry towel. Do not use solvents over surfaces
with a dry towel. Do not use solvents over surfaces
or structural tubes.
or structural tubes.
Surfaces must be cleaned with a
Surfaces must be cleaned with a
MODEL RTA-S06
MODEL RTA-S06

Advertisement

loading

Related Manuals for Techni Mobili RTA-S06

Summary of Contents for Techni Mobili RTA-S06

  • Page 1 Thanks for purchasing one of our products, please read carefully the assembly instructions before the installation (Attention: Do not tighten the screws before instructions before the installation (Attention: Do not tighten the screws before all screws are in place). all screws are in place). MODEL RTA-S06 MODEL RTA-S06 B15 090521...

  • Page 2: Instrucciones De Ensamblaje

    ó ó sobre esta un trapo seco. No utilice solventes, MODELO RTA-S06 MODELO RTA-S06 sobre las superficie ni las estructuras tubulares. Gracias por comprar uno de nuestros productos por favor lea cuidadosamente las instrucciones de ensamblaje antes de instalar la unidad.(Atencion: No adjuste firmemente los tornillos antes de tener la...

  • Page 3: Parts List

    RTA-S06 PARTS LIST PARTS LIST LISTA DE PARTES Top Drawer Right Panel Top Drawer Left Panel Top Drawer Front Panel Casters Panel Izquierdo de Panel Derecho de Panel Frontal de Gaveta Superior Gaveta Superior Ruedas Gaveta Superior Bottom Drawer Left...
  • Page 4 RTA-S06 Top Panel Back Panel L Bracket Front Wheel Panel Superior Angulo de Soporte Panel Posterior Rueda Frontal A,B,C-Metal Fittings; D-Lock; E-Metal Plate; F-Screws; G-Key Support Tubes Top Glass Panel A,B.C-Accesorios de Metal; D-Cerradura; E- Tubos de Soporte Vidrio del Panel Superior Placa de Metal;...
  • Page 5 RTA-S06 6X40MM BOLT INSTALLATION AS BELOW: 6x40mm INSTALE EL PERNO ASI: Bolt Perno Connecting piece Adjust connecting piece direction if Insert bolt when Connecting piece Pieza de ajuste condition as illustrated under Such condition Cuando la pieza de ajuste este...
  • Page 6 RTA-S06 SCREWS SCREWS TORNILLOS TORNILLOS 6X40 MM 4PCS Insert the Bolts A in the holes of the back face of the Top Drawer Front Panel (4) and tighten them with the screwdriver, then place the Top Drawer Left Panel (1) and the Top Drawer Right Panel (2) over the Bolts and tighten the nuts on the inside face.
  • Page 7 RTA-S06 Izquierdo Align selected holes on slides as illustrated with pre- Left drilled holes on drawer box before inserting screws Derecho Haga coincidir los agujeros seleccionados en los Right Deslizadores con los agujeros pre-taladrados sobre el cajón de la gaveta(como indica la ilustración) antes de insertar los tornillos.
  • Page 8 RTA-S06 SCREWS SCREWS TORNILLOS TORNILLOS 6X40 MM 4PCS Insert the Bolts A in the holes of the back face of the Bottom Drawer Front Panel (9) and tighten them with the screwdriver, then place the Bottom Drawer Left Panel (7) and the Bottom Drawer Right Panel (8) over the Bolts and tighten the nuts on the inside faces.
  • Page 9 RTA-S06 Izquierdo Left Align selected holes on slides as illu Derecho strated with pre-drilled holes on Right drawer box before inserting screws 2PCS Haga coincidir los agujeros seleccionados en los Deslizadores con los agujeros pre-taladrados sobre el cajón de la gaveta(como Indica la ilustración) antes de...
  • Page 10 RTA-S06 P.10 Tighten the metal plates on the marked position of the metal bar SCREWS SCREWS TORNILLOS TORNILLOS 4X20 MM First Slide into the Metal Bar (23E) the 4 Metal 2PCS Fittings in the order shown in the drawing (23A,23C,23C,23A). Then, tighten the metal plates 23C on the marked position of the Metal Bar (23E) with 23F.
  • Page 11 RTA-S06 P.11 SCREWS SCREWS TORNILLOS TORNILLOS 3X15 MM 2PCS 2PCS Right Left 8PCS Derecho Izquierdo Match the Sliders (12) with the holes of the inside faces of the Left & Right Panels (14 & 15). Then fix the fixed part to the Panels using screws C.
  • Page 12 RTA-S06 P.12 Slide in Back Panel (17) between the Left & Right Panels (14 & 15). Deslice el Panel Posterior (17) entre los Paneles Izquierdo y Derecho (14 y 15). SCREWS SCREWS TORNILLOS TORNILLOS 6X40 MM 4PCS Insert the Bolts A in the holes of the Top Panel (18) and put it over the Left & Right Panels (14 &...
  • Page 13 RTA-S06 P.13 2PCS 2PCS SCREWS SCREWS TORNILLOS TORNILLOS 4X14 MM 16PCS Use screws E to fix the Casters (3) to the Bottom Panel (16). Use tornillos E para fijar las Ruedas (3) al Panel Inferior (16). 4PCS SCREWS SCREWS TORNILLOS...
  • Page 14 RTA-S06 P.14 SCREWS SCREWS TORNILLOS TORNILLOS 6X25 MM 4PCS Use screws H to assemble the Support Tubes (21) with the Top Panel (18). Use tornillos H para ensamblar los Tubos de Soporte (21) con el Panel Superior (18). Slide in the drawers. Tighten all screw well and enjoy the cabinet.
  • Page 17 TECHNI MOBILI CHAIR WARRANTY 2-YEAR WARRANTY R TA Products, LLC has warranted the Techni Mobili o ce chairs to the original purchaser who acquired a new product from RTA Products or its authorized resellers of the product against defects in material or workmanship.
  • Page 18 Product Warranty - RTA Products http://rtaproducts.com/product-warranty.h Any modi cation to the original product voids the warranty. We do not warrant the performance of the product when used in combination with other than original products. This product has been designed for and is intended for o ce and home-o ce use only. This warranty is Original Purchaser’s sole remedy for product defects, and this warranty does not extend to any product, or damage to any product, caused by or attributed to abuse or misuse, products used for commercial or rental purposes, use modi cations of, or attachments to the product, and products or parts not used, maintained, or extended hereunder is in lieu of any and all other warranties, express or implied, including without...
