Summary of Contents for Techni Mobili RTA-S19
- Page 1 RTA-S19 Assembly Instructions REV.1-PFT-8599-0125 support@rtaproducts.com technimobili.com...
-
Page 2: Main Parts List
RTA-S19 MAIN PARTS LIST Left panel Right panel Left frame Right frame Bottom panel Back panel Middle shelf Top panel Middle support Small drawer Small drawer left Small drawer front right... - Page 3 RTA-S19 MAIN PARTS LIST Small drawer Small drawer File drawer front back bottom " . 7 5 " File drawer left File drawer right File drawer back File drawer File rods Drawer sliders, bottom Set of 4 pcs. . 2 "...
-
Page 4: Hardware List
RTA-S19 Main Parts Layout (For reference) 21 (Right) (left) Hardware List M6x25 M5x40 M3.5x14 M3.5x18 Ø15x10 M5x42 M6x42 16 PCS 8 PCS 24 PCS 4 PCS 34 PCS 4 PCS 18 PCS M4x18 2 PCS 4 PCS 1 PCS 1 PCS... -
Page 5: Assembly Steps
RTA-S19 ASSEMBLY STEPS Assemble #1 to #3 with screws E. M5x40 5 PCS ( T o ( T o ( T o M3.5x14 FIRST: Attach only the Left "Flat" sliders #21 to M5x42 M6x42 #1 with screws F. 4 PCS... - Page 6 RTA-S19 M5x40 Assemble #2 to #4 with screws E. 5 PCS n t ) n t ) n t ) M3.5x14 FIRST: Attach only the Right "Flat" sliders #21 to M5x42 M6x42 #1 with screws F. 4 PCS 4 PCS...
- Page 7 RTA-S19 Ø15x10 FIRST: Join #7 to #1. 2 PCS n t ) n t ) THEN: insert the cam locks C into #7, and turn them to secure and lock the pieces together. Ø15x10 Assemble #6 to #3 by inserting and turning cam locks C into #6.
- Page 8 RTA-S19 Ø15x10 Assemble #5 to #3 with cam locks C as done before. 2 PCS Ø15x10 Assemble #9 to #1 with cam locks C. 2 PCS n t )
- Page 9 RTA-S19 Ø15x10 Assemble #2 and #4 to #5, #6, #7 and #9 with cam locks C as done before. 8 PCS n t ) M3.5x14 Attach the casters #23 to #5 with screws F. r o n 16 PCS...
- Page 10 RTA-S19 P.10 M3.5x14 Assemble #22 to #7 with screws F. 2 PCS M6x25 FIRST: Assemble #8 to #3 and #4 with screws D. 4 PCS THEN: Pass the cable from #22 through the hole of #6 and the grommet #24, and fit...
- Page 11 RTA-S19 P.11 M5x40 FIRST: Assemble #13 to #11 and #12 with screws E. THEN: Slide #14 through 4 PCS #11 and #12 and into #13. M4x18 Ø15x10 M5x42 FIRST: Attach the bolts A into the indicated holes on #10. 4 PCS...
- Page 12 RTA-S19 P.12 M3.5x14 Attach the "L" shaped sliders #21 to the bottom of the drawer with screws F, making sure the wheels go towards the back of the drawer. 4 PCS When finished, the sliders on ( F r the drawer will look like this:...
- Page 13 RTA-S19 P.13 M5x40 M4x18 M3.5x18 4 PCS 4 PCS 1 PCS 2 PCS 1 PCS FIRST: Assemble #18 to #16 and #17 with screws E, and with the rods #20 in between #15 and #18. THEN: Attach the handle H to #15 with screws I.
- Page 14 RTA-S19 P.14 M3.5x14 Attach the "L" shaped sliders #21 to the bottom of the drawer with screws F. The wheels go facing towards the back. 4 PCS n t ) When finished, the sliders on the drawer will look like this:...
