Five-pin socket：For connecting the radio receiver and five-pin plug socket.
Mini USB Interface
Mini USB intreface
For connection to the host and external devices, upgrade firmware and
download the static data, can also be used as USB to serial port using a special
mode of operation (need to install drivers, see Annex 4).
Mini USB cable
Figure 5-4
Figure 5-5
Plug the red dot
Socket red dot
