U Disk Data Download - Hi-Target V90 Plus Manual

HI-TARGET
For more information about the hand-book, read "Hi-Survey Software
User's Guide."

U disk data download

Receiver file management is stored by USB drive. It can be used upon
inserting and download by dragging directly without download programs. It
can only download static data and unable to write or read the receiver.
The receiver can download USB drive data with Y-type data cable, one
end is connected to computer USB and the other end is connected to eight-core
socket on bottom of receiver. After connection, "static" disk and SD card will
appear in computer. After opening the disk, it can copy the collected static file.
The steps to modify point name and antenna height of downloaded static
file are:
1. Choose *. GNS and double click the mouse.
2. Pop up the dialogue of "file edit" to modify point name and input antenna
height, and then click "ok".
26
Figure 3-5
