SelectBlinds S-300 Installation Instructions Manual

Cassette

Advertisement

Tape Measure
S-300 Brackets
Shade Width (") # of Brackets Supplied
0 - 60
60 - 84
84+
STEP 1 - BRACKET INSTALLATION
Inside Mount
Mark the cassette placement on the mounting surface. Install the brackets approximately 2" from either end of the
cassette (drywall plugs, if required, can be purchased from a local hardware store). Ensure each bracket is level and
in alignment with one another. Brackets should be securely placed allowing slight movement to adjust.
©2022 Select Blinds
REQUIRED TOOLS FOR INSTALLATION
CASSETTE, MODELS S-300 | S-325 | V-80 | V-90
Level
COMES WITH YOUR ORDER
S-325 / V-80 / V-90 Brackets
2
3
4
CASSETTE INSTRUCTIONS
Cassette Installation Instructions
Power Drill / Screwdriver
Screws
Outside/Wall Mount
Pencil
Applications
Roller Shades
High-Lite Shades
Sheer Horizontal
Cassette Installation Instructions
1
|

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the S-300 and is the answer not in the manual?

Questions and answers

Summary of Contents for SelectBlinds S-300

  • Page 1 Cassette Installation Instructions REQUIRED TOOLS FOR INSTALLATION CASSETTE, MODELS S-300 | S-325 | V-80 | V-90 Tape Measure Level Pencil Power Drill / Screwdriver COMES WITH YOUR ORDER S-300 Brackets S-325 / V-80 / V-90 Brackets Screws Applications Roller Shades...
  • Page 2 3 1/8” H x 3 1/2” W 3 3/8” H x 3 1/8” W 5” H x 3 7/16” W STEP 2 - MOUNTING THE SHADE (S-300 | S-325) STEP 2 - MOUNTING THE SHADE (V-80 | V-90) Snap in...
  • Page 3: Maintenance And Care

    Cassette Installation Instructions STEP 4 - APPLIES TO CHAINGUARD ONLY CHILD/SAFETY CHAIN TENSIONER INSTALLATION This device MUST be properly installed in accordance with Health Canada regulations on corded window covering products. Fasten P-Clip against the window frame or wall. Position the P-Clip so it does not interfere with the travel of the shade.
  • Page 4: How To Operate

    Cordless Operating Instructions HOW TO OPERATE WANDCONTROL To operate your shade, gently pull down on the wand repeatedly until shade reaches desired position. If the shade operates in the opposite direction, securely dock the wand into the housing and twist the handle clockwise or counterclockwise until you hear a click. The click indicates change in direction.
  • Page 7: Smart Controller

    SMART CONTROLLER ENGLISH SETUP CODE System requirements CODE DE CONFIGURATION • A strong WiFi signal (3 bars or more) in the location where you will setup your Smart Controller. • The Smart Controller only supports 2.4GHz WiFi (IEEE 802 11b/g/n), not 5GHz. WiFi security needs to be set to WPA-PSK or L2019 E8965 N2421...

This manual is also suitable for:

S-325V-80V-90
