Tape Measure
S-300 Brackets
Shade Width (") # of Brackets Supplied
0 - 60
60 - 84
84+
STEP 1 - BRACKET INSTALLATION
Inside Mount
Mark the cassette placement on the mounting surface. Install the brackets approximately 2" from either end of the
cassette (drywall plugs, if required, can be purchased from a local hardware store). Ensure each bracket is level and
in alignment with one another. Brackets should be securely placed allowing slight movement to adjust.
©2024 Select Blinds V5-092024
REQUIRED TOOLS FOR INSTALLATION
CASSETTE, MODELS S-300 | S-325 | V-80 | V-90
Level
Power Drill / Screwdriver
COMES WITH YOUR ORDER
S-325 / V-80 / V-90 Brackets
2
3
4
CASSETTE INSTRUCTIONS
Cassette Installation Instructions
Pencil
Screws
Applications
Outside/Wall Mount
Cassette Installation Instructions
Roller Shades
High-Lite Shades
Sheer Horizontal
|
1
Advertisement
Table of Contents
Related Manuals for SelectBlinds S-300
Summary of Contents for SelectBlinds S-300
- Page 1 Cassette Installation Instructions REQUIRED TOOLS FOR INSTALLATION CASSETTE, MODELS S-300 | S-325 | V-80 | V-90 Tape Measure Level Pencil Power Drill / Screwdriver COMES WITH YOUR ORDER S-300 Brackets S-325 / V-80 / V-90 Brackets Screws Applications Roller Shades...
- Page 2 3 1/8” H x 3 1/2” W 3 3/8” H x 3 1/8” W 5” H x 3 7/16” W STEP 2 - MOUNTING THE SHADE (S-300 | S-325) STEP 2 - MOUNTING THE SHADE (V-80 | V-90) Snap in...
- Page 3 Cassette Installation Instructions STEP 4 - AFFIX U-CLIP TO WALL (CHAINGUARD ONLY) CHILD/SAFETY CHAIN TENSIONER INSTALLATION If preferred, the U-Clip can be affixed to the wall to prevent the chain from swaying. Position the U-Clip so it does not interfere with the travel of the shade. Chain should be tight, but not under stress when U-Clip is affixed to the wall. To do so, remove the screw at the front of the U-Clip and gently pry the cover off.
-
Page 4: How To Operate
Cordless Operating Instructions HOW TO OPERATE CAUTION: Do not lower the shade past the ordered length because damage may occur to the shade. SPRINGDRIVE To lower your shade, grasp the bottom bar (handle) from the centre-point and gently pull the shade down to desired position. To raise your shade, give a slight pull on bottom bar handle, and the shade will raise automatically in a gradual and controlled motion, stopping at the top. - Page 5 Cordless Operating Instructions SPRINGDRIVE SPRINGDRIVE FREQUENTLY ASKED QUESTIONS 1. HOW DO I ADJUST THE TENSION IF MY SHADE ISN’T RISING FAST ENOUGH? To make your install faster and more efficient, each SpringDrive™ system is pre-tensioned in our factory, and precisely tuned according to the weight and dimensions of your shade.
- Page 6 BASICS Motor User Guide AM25 AM22 Channel LED Lights ON/OFF Toggle I. Operation Instruction Remote battery: CR2032 1. Power ON/OFF OR Sleep/Wake 2. Pairing Remote AM25 Model only Ensure toggle is in ON Press P1 button on motor To wake, press P1 Select channel on your Press and hold UP position.
-
Page 7: Troubleshooting
9. Adding Remotes or Channels 10. Deleting Remotes or Channels Select remote/channel to be Press and hold S1 for 1 second On current remote/channel, Select new remote/channel deleted and press and hold and the motor will jog to press and hold “STOP” until and press “UP”. -
Page 8: Smart Controller
SMART CONTROLLER ENGLISH SETUP CODE System requirements CODE DE CONFIGURATION • A strong WiFi signal (3 bars or more) in the location where you will setup your Smart Controller. • The Smart Controller only supports 2.4GHz WiFi (IEEE 802 11b/g/n), not 5GHz. WiFi security needs to be set to WPA-PSK or SBCAN WPA2-PSK.
