- Page 1 INSTALLATION INSTRUCTIONS Lift & Lock™ for Horizontal Blinds 6/2016...
-
Page 2: Mounting Brackets
Installating Your New Horizontal Blinds Please take a moment to review the contents of your package. Your package should contain the following: 1. Left and Right Box Style Mounting Brackets 2. Mounting Bracket Screws, Two per Blind are provided. 3. Valance Clips (valance attachment varies by product) 4. - Page 3 Brackets Required All blinds require two mounting brackets (included). All 2 on 1 blinds receive one support bracket. All 3 on 1 blinds receive two support brackets. Center support brackets for 2 on 1 and 3 on 1 blinds should be placed between blind panels.
-
Page 4: Optional Components
Valance Installation The type of valance attachment included in your package will vary depending on the product you have ordered. Several products utilize the magnet system which allows you to simply place the valance directly on to the headrail. No clips are necessary. - Page 5 Optional Components Extension Bracket Attach 2” or 4” extension brackets to the mounting surface in the same locations where the end brackets and intermediate brackets would be attached. Use the provided screws to mount each extension bracket. IMPORTANT: The tops of the end brackets and intermediate bracket(s) must align.
- Page 6 Raising and Lowering the Blind To Raise the Blind: - Prior to raising or lowering, tilt the slats to the open position using the tilt mechanism on the left or right side of the blind. - Grasp the bottom rail near the center with one hand while balancing the bottom rail with your other hand.
-
Page 7: Troubleshooting
Troubleshooting Problem: The bottomrail is not level or the blind hangs crooked Solution: Check that the headrail and installation brackets are level and aligned. Shim the installation brackets if necessary. NOTE: All skew adjustment features are located under the headrail. To level the blind, raise the low side of the bottom rail by turning the screw adjustment feature on the headrail clockwise with a coin or screwdriver while lifting the weight from the bottom rail. -
Page 8: Child Safety
Removing the Blind - if necessary - Fully raise the blind - Remove the valance. - Push up on the bottom of the bracket to release the locking tab. - Carefully pull the blind to remove it from the brackets. Child Safety Young children can STRANGLE in cord loops.
