SelectBlinds Classic Installation Manual

INSTALLATION GUIDE
ROMAN SHADES
LIFT SYSTEMS: CONTINUOUS CORD LOOP | MOTORIZATION
The difficulty level of this installation is ranked at Level 1. A piece of cake!
If you have questions or get stuck, call our Customer Care Team at 888-257-1840, or email customercare@selectblinds.com
HARDWARE AND PARTS INCLUDED
BRACKET SCREWS
WALL TENSION DEVICE
ANCHORS* (Continuous Loop)
*Recommended if mounting into hollow drywall.

MOUNTING THE BRACKETS

1.
NOTE: Before installing an inside mount motorized shade, you need to
first attach the battery pack to the backside of the headrail.
Figure A: Slide the two plastic clips into place in the groove, from the side
of the battery pack.
Figure B: Clip the motor cable into the battery pack. Be sure the antenna
cable is positioned away from the headrail, and out of contact with
anything metal.
TIP: The back of each bottom rail should have a tag with a number. This
indicates the channel and remote that the shade is pre-programmed to.

INSIDE MOUNT

1. Measure 2"- 4" in from each side of the window frame, and mark once
with a pencil for your outer brackets. The front of the bracket will face out
from the window, and the back of it will hang down parallel to the window.
NOTE: Leave marks for any additional brackets you need, evenly spaced
between your first two marks. If using your own screws instead of those
provided, be sure to pre-drill a small hole with a 5/64" drill bit before the
final screws go in to attach brackets.
2. Center the brackets over your marks, and set them back until the front
of the bracket meets the edge of your window. Mark through the top hole
in the bracket with your pencil. This is where your screws will go.
3. Align each bracket with your screw holes and drill the screws securely
into place.
*If you are using wall anchors, pre-drill with a 1/4" bit instead, and tap the
wall anchors into the holes with a hammer before drilling in the screws.
®
Simple. Smart. Custom.
BATTERY CHARGER & REMOTE
(Motorized)
INSTALLATION GUIDE | ROMAN SHADES
TOOLS REQUIRED
PENCIL TAPE MEASURE
PHILLIPS SCREWDRIVER
Figure A
BATTERY
PACK
HEADRAIL
SHADE FABRIC
BACK
Simple. Smart. Custom.
POWER DRILL
PHILLIPS DRILL BIT
5/64" DRILL BIT STEP LADDER
Figure B
MOTOR
ANTENNA CABLE
SWING-ARM
FRONT
UPDATED DEC 2021
®
1
