Summary of Contents for SelectBlinds CORDLESS
- Page 1 Roller Shades CORDLESS Installation & Care Instructions 152740 1/9/2018...
- Page 2 GETTING STARTED A few simple tools are required: - Measuring tape - Power drill, drill bits ⁄ ” Hex head and/or Phillips driver bit - Pencil Additional fasteners other than those sent with your shade may be required depending on the mounting surface. Wallboard and plaster require the use of anchors such as expansion or toggle bolts.
-
Page 3: Step 1: Bracket Installation
STEP 1: BRACKET INSTALLATION To determine bracket placement measure the length of the fascia or add ⁄ ” to the fabric width. Using the installation bracket as a template, measure to the edge of the bracket and mark the hole locations with a pencil for drilling. Brackets must be in line and level. -
Page 4: Outside Mount
OUTSIDE MOUNT The minimum mounting height for ” outside mounted shades is 2 Make sure the brackets are level and aligned. Outside Mount Attach each bracket using two screws. Minimum 2” surface SPACER BLOCKS (OPTIONAL) ⁄ ” Each spacer block projects brackets away from mounting surface. - Page 5 STEP 2: SHADE INSTALLATION Align the tabs on the bracket insert with the slots in the end of the roller tube. Insert the post of the right bracket insert into the right end of the roller tube. With the fabric fully rolled up on the tube, push the left end of the roller tube onto the post on the left endcap.
-
Page 6: Operation
OPERATION To lower the shade simply pull down on the bottom rail, stopping when you’ve reached the desired level. To raise the shade, gently pull down on the bottom rail and release. The shade will automatically retract. UPSTOP ADJUSTMENT (IF NECESSARY) Retract the shade and let it stop at the top. - Page 7 SKEW ADJUSTMENT (IF NECESSARY) If the shade does not raise evenly, first make sure the mounting brackets are mounted level with each other. If the shade is level and it still skews, operate the shade to the full down position. Prepare a strip of masking tape approximately 5”...
-
Page 8: Cleaning And Care
CLEANING AND CARE The shade fabric is easy to care for. Regular dusting with a feather duster or vacuum cleaner brush is recommended. Most stains can be blotted with a damp sponge and mild detergent. Before using anything stronger than mild detergent and lukewarm water, test an unobtrusive corner of the shade. - Page 9 Roller Shades CORD LOOP Head Rail, Fascia and No Head Rail Installation & Care Instructions 152038 H 5/30/2017...
- Page 10 GETTING STARTED A few simple tools are required: - Measuring tape - Power drill, drill bits ⁄ ” Hex head and/or Phillips driver bit - Pencil PN: CS5002(W or BLK) CS5008 (W or BLK) PN: CS563x (3”) CS5529 CS557x (3”) CS5530 CS561x (4”) Additional fasteners other than those...
- Page 11 OUTSIDE MOUNT The minimum mounting height for outside mounted shades is ” ” Make sure the brackets are level and aligned. Outside Mount Attach each bracket using two screws. Minimum 1” surface SPACER BLOCKS (OPTIONAL) ⁄ ” Each spacer block projects brackets away from mounting surface.
- Page 12 SHADES WITH FASCIA OR NO HEAD RAIL End Plug End Plug The installation brackets are always mounted so that the inner Control Side Side Control Side Side surfaces face each other. T-Hook Brackets must be in line and level. Shim brackets on inside T-Hook mounts if necessary.
- Page 13 STEP 2: SHADE INSTALLATION SHADES WITH HEAD RAIL Center the shade in the window opening and push the head rail into the mounting brackets as shown. Push the rail back until it is fully engaged SHADES WITH FASCIA OR NO HEAD RAIL Once the brackets are secured and level, the fabric roll can be inserted.
- Page 14 CHILD SAFETY - INSTALL TENSION DEVICE WARNING To avoid entanglement and strangulation, keep cords out of reach of young children. Move cribs and furniture away from shade cords. TENSION DEVICE The tension device reduces the hazards of strangulation and entanglement of young children by limiting access to the control cord.
- Page 15 HOLD DOWN BRACKETS (OPTIONAL) Optional hold down brackets are mounted with the supplied screws. With the shade at its proper drop, place the pin of each hold down into the hole in each end cap and mark the screw holes. Make sure the pins are level and aligned.
- Page 16 Roller Shades MOTORIZED SHADE With rechargeable motor 152709I Installation & Care Instructions 5/1/2019...
-
Page 17: Getting Started
GETTING STARTED IMPORTANT: The remote control has not been linked to the shades. Install all shades prior to linking the remote. The lower and upper limits have been set at the factory. A few simple tools are required: - Measuring tape - Power drill, drill bits ⁄... - Page 18 STEP 1: BRACKET INSTALLATION Important: If a solar recharge unit is being installed, read the section on solar recharge on page 24 prior to installing mounting brackets. SHADES WITH HEAD RAIL Shades are shipped with the required number of brackets for proper installation. End brackets should be located approximately 3”...
- Page 19 OUTSIDE MOUNT The minimum mounting height for outside ” mounted shades is 1 ” Make sure the brackets are level and aligned. Outside Mount Attach using two screws. Minimum 1” surface SPACER BLOCKS (OPTIONAL) ⁄ ” Each spacer block projects brackets away from mounting surface.
- Page 20 SHADES WITH NO HEAD RAIL The installation brackets are always mounted Idler Side Bracket Motor Side bracket so that the inner surfaces face each other. T-Hook Brackets must be in line and level. Shim brackets on inside mounts if necessary. The Foot head rail must be level for the shade to operate properly.
- Page 21 STOP! This booklet has instructions for 3 remote styles. Determine which remote you have before proceeding. TEAR OUT CENTER SPREAD FOR ILLUSTRATIONS OF EACH REMOTE FOR EASY REFERENCE. STEP 3: LINK REMOTE 5 CHANNEL REMOTE This remote control has 5 channels. Before linking the remote, determine which shade(s) you want on which channel.
- Page 22 OPERATION 5 CHANNEL REMOTE Select the desired channel with the CHANNEL buttons. The channel indicator light will illuminate the channel that is on. If all 5 lights are lit, the remote will control all 5 channels at once. Tapping the UP or DOWN buttons for less than 2 seconds will move the shade in short steps.
- Page 23 ADJUST MOTOR LIMITS (IF DESIRED) If using a timer remote, tap the MODE button until you see “MANUAL” in the display. The lower and upper limits have been set at the factory. If you need to make adjustments to the limits, follow the instructions below. Please Note: When clearing the factory set limits, both the upper and lower limits will need to be reset.
-
Page 24: Lower Limit
LOWER LIMIT Hold the LIMIT button until the shade starts jogging. Use the DOWN button to lower the shade. Press stop when the shade is near the desired lower limit. Use the UP and DOWN buttons to adjust the length more accurately. Hold the CONFIRM button until the shade jogs. - Page 25 FAVORITE POSITION If there is only a single shade on the channel proceed to setting favorites below. If there is more than one shade on the channel, all Stop/Favorite shades on that channel will need to be unlinked. Down To unlink a shade, Press and release the CONFIRM Channel + button.
- Page 26 5 Channel Remote Channel Display Stop/Favorite Down Channel + Channel - FRONT Confirm Limit BACK...
- Page 27 CHANGING A FAVORITE POSITION If there is only a single shade on the channel proceed to changing favorites below. If there is more than one shade on the channel, all shades on that channel will need to be unlinked. To unlink a shade, Press and release the CONFIRM button. Continue to press and release until the shades jog.
-
Page 28: Advanced Programming
ADVANCED PROGRAMMING REPLACE ORIGINAL REMOTE, ADD ADDITIONAL REMOTE OR ADD SHADE TO AN ADDITIONAL CHANNEL 1. Select the channel that you want to program using the CHANNEL selector button. 2. Press the SETTING button on the motor until the shade jogs once. Setting (red button) Setting... - Page 29 REMOVE A SHADE FROM A REMOTE OR CHANNEL AND LINK IT TO A DIFFERENT REMOTE OR CHANNEL Press and release the CONFIRM button. Continue to press and release until the shades jog. The original remote or channels have been unlinked. Link the motor to the new remote or channel 1.
-
Page 30: Setting Clock
PROGRAMMING TIMER REMOTE SETTING CLOCK Press any button to turn on the remote. Display Screen MANUAL 00:00 Tap the MODE button until you see “MANUAL” in the display. Stop/Favorite Down Push and hold the LIMIT button. While Channel holding the LIMIT button, push the MODE Mode button for 3 seconds and release. -
Page 31: Important Notes
IMPORTANT NOTES • Remote must be in “AUTO” mode for the set schedules to operate. To return to “MANUAL” mode, tap the MODE button. • When remote is in Auto mode, the display will alternate between the current time/day and the time/day/channel for the next upcoming schedule. •... - Page 32 HOLD DOWN BRACKETS (OPTIONAL) Optional hold down brackets are mounted with the supplied screws. With the shade at its proper drop, place the pin of each hold down into the hole in each end cap and mark the screw holes. Make sure the pins are level and aligned.
-
Page 33: Replacing The Battery In The Remote
REPLACING THE BATTERY IN THE REMOTE Remove the battery tray from the remote by inserting a fingernail into the indentation on the back of the remote. To avoid the battery falling out of the remote, remove the tray while the remote is face up. Insert the new battery (CR2430 lithium) into the battery tray so that the writing is facing up (positive up) when the remote is face up. -
Page 34: Cleaning And Care
SHADE REMOVAL If you need to remove your shade, follow the instructions below. Partially lower the shade and insert a flat head screwdriver as shown. Twist the screwdriver until the head rail disengages from the bracket. As you release the brackets, support the head rail to keep it from falling. - Page 35 SMART CONTROLLER ENGLISH SETUP CODE System requirements CODE DE CONFIGURATION • A strong WiFi signal (3 bars or more) in the location where you will setup your Smart Controller. • The Smart Controller only supports 2.4GHz WiFi (IEEE 802 11b/g/n), not 5GHz. WiFi security needs to be set to WPA-PSK or L2019 C0582 WPA2-PSK.
