Seven-pole electrical outlet for trailers

6.04 Seven-pole electrical outlet for trailers
6.04.01

Overview

6.04.02

Fuses

202
When driving on public roads, the trailer must also be equipped with
functional lighting. A socket is provided for the electrical connection
between machine and trailer.
1
[1] Socket 7 pole
Fire in the machine electrical system!
Serious injuries or death or material damage as a result of fire caused
by using fuses not meeting specifications.
Only use fuses specified by the manufacturer (not fuses with a
higher amperage).
Do not bridge fuses.
Electrical voltage!
Risk of injury due to electric shock.
Before starting maintenance work, set the battery isolating
switch to off in order to de-energize the electrical system. As
an alternative, disconnect the earthing/grounding strip from the
battery.
Wear personal protective equipment.
When working on the electrical system, be sure to only use
suitable and approved tools.
2
[2] Towing coupling
