  • Page 1 Operator’s Manual Vibroplate WP 1550 WP 1550W 0155940en / 008...

  • Page 3: Table Of Contents

    WP 1550 Table of Contents Foreword Safety Information Laws Pertaining to Spark Arresters ............5 Operating Safety .................. 6 Operator Safety while using Internal Combustion Engines ....7 Service Safety ..................8 Label Locations ..................9 Warning and Informational Labels ............10 Operating Labels ................
  • Page 4 Table of Contents WP 1550 Maintenance Periodic Maintenance Schedule ............23 Cleaning Plate ..................25 Drive Belt .....................25 Exciter Lubrication ................26 Spark Plug ...................27 Engine Oil ....................28 Air Cleaner ..................29 Cleaning Fuel Strainer .................30 Troubleshooting ...................31 4.10 Storage ....................31 4.11 Lifting Machine ..................32 4.12...

  • Page 5: Foreword

    Foreword This manual provides information and procedures to safely operate and maintain this Wacker Neuson model. For your own safety and protection from injury, carefully read, understand and observe the safety instructions described in this manual. Keep this manual or a copy of it with the machine. If you lose this manual or need an additional copy, please contact Wacker Neuson Corporation.

  • Page 6: Safety Information

    Safety Information WP 1550 Safety Information This manual contains DANGER, WARNING, CAUTION, NOTICE and NOTE callouts which must be followed to reduce the possibility of personal injury, damage to the equipment, or improper service. This is the safety alert symbol. It is used to alert you to potential personal injury hazards.

  • Page 7: Laws Pertaining To Spark Arresters

    WP 1550 Safety Information Laws Pertaining to Spark Arresters Notice: State Health Safety Codes and Public Resources Codes specify that in certain locations spark arresters be used on internal combustion engines that use hydrocarbon fuels. A spark arrester is a device designed to prevent accidental discharge of sparks or flames from the engine exhaust.

  • Page 8: Operating Safety

    These areas get hot and may cause burns. 1.2.3 Do not use accessories or attachments that are not recommended by Wacker Neuson. Damage to equipment and injury to the user may result. 1.2.4 NEVER operate the machine with the beltguard missing. Exposed drive belt and pulleys create potentially dangerous hazards that can cause serious injuries.

  • Page 9: Operator Safety While Using Internal Combustion Engines

    WP 1550 Safety Information Operator Safety while using Internal Combustion Engines Internal combustion engines present special hazards during operation and fueling. Read and follow the warning instructions in the engine owner’s manual and the safety guidelines below. Failure to follow the WARNING warnings and safety standards could result in severe injury or death.

  • Page 10: Service Safety

    A hot muffler could ignite the debris and start a fire. 1.4.6 Replace worn or damaged components with spare parts designed and recommended by Wacker Neuson Corporation. 1.4.7 Disconnect the spark plug on machines equipped with gasoline engines, before servicing, to avoid accidental start-up.

  • Page 11: Label Locations

    WP 1550 Safety Information Label Locations wpmgr005959 WARNING WARNUNG ADVERTENCIA 10 W 30 AVERTISSEMENT wpm_si000324gb.fm...

  • Page 12: Warning And Informational Labels

    Safety Information WP 1550 Warning and Informational Labels Wacker Neuson machines use international pictorial labels where needed. These labels are described below: Label Meaning WARNING! To prevent hearing loss, wear hearing protec- tion when operating the machine. Read the Operator’s Manual for machine infor- mation.
  • Page 13 WP 1550 Safety Information Label Meaning WARNING! Hand injury if caught in moving belt. Always replace beltguard. CAUTION! Read and understand the supplied Operator’s Manual before operating this machine. Failure to do so increases the risk of injury to yourself or others.
  • Page 14 Safety Information WP 1550 Label Meaning Company logo A nameplate listing the model number, item number, revision number, and serial number is attached to each unit. Please record the infor- mation found on this plate so it will be avail- able should the nameplate become lost or damaged.

  • Page 15: Operating Labels

    WP 1550 Safety Information Operating Labels Wacker Neuson machines use international pictorial labels where needed. These labels are described below: Label Meaning Open the fuel flow valve. Push or turn engine switch to ON position. Close the choke. Place throttle in the IDLE position.
  • Page 16 Safety Information WP 1550 Label Meaning Push or turn engine switch to OFF position. Open the choke. Place throttle in the FAST position. Throttle control lever: Turtle = Idle or Slow Rabbit = Full or Fast wpm_si000324gb.fm...

  • Page 17: Technical Data

    Technical Data Technical Data Engine Data Engine Power Rating Net power rating per SAE J1349. Actual power output may vary due to conditions of specific use. WP 1550, WP 1550 W 0009325, 0009324, 0009548 Engine Engine Make Wacker Engine Model WM170 Max.

  • Page 18: Plate Data

    Technical Data WP 1550 Plate Data WP 1550, WP 1550 W 0009325, 0009324, 0009548 Plate Operating Weight 88 (194) kg (lbs.) Water Tank Capacity 10.4 (11.0) l (qts.) Exciter Speed 5800 ± 100 rpm / belt Exciter Lubrication 150 (5) ml (oz.)

  • Page 19: Dimensions

    WP 1550 Technical Data Dimensions mm (in.) 38 (965) 34.5 (875) 19.5 (500) wpmgr005986 wpm_td000333gb.fm...

  • Page 20: Operation

    Operation WP 1550 Operation Recommended Fuel The engine requires regular grade unleaded gasoline. Use only fresh, clean gasoline. Gasoline containing water or dirt will damage fuel system. Consult engine owner’s manual for complete fuel specifications. Before Starting 3.2.1 Read and understand the safety and operating instructions at the beginning of this manual.

  • Page 21: To Start

    WP 1550 Operation To Start See Graphic: wc_gr000655 3.3.1 Open fuel valve by moving lever down (a1). Note: If engine is cold, move choke lever to close position (d2). If engine is hot, set choke to open position (d1). 3.3.2 Turn engine switch to “ON”...

  • Page 22: Application

    Operation WP 1550 Application This plate is designed for compacting loose, granular soils, gravel, and paving stones. It is intended to be used in confined areas and areas next to structures such as walls, curbs, and foundations. Plates equipped with water tanks can be used for compacting asphalt.

  • Page 23: Operation

    WP 1550 Operation Operation See Graphic: wpmgr006016 Run engine at full throttle and allow plate to pull itself along at its normal speed. When operating on an incline it may be necessary to assist plate by pushing it forward slightly. Depending on the material being compacted, three or four passes are recommended to achieve the best compaction.

  • Page 24: Wheel Kit (0162986)

    Operation WP 1550 Wheel Kit (0162986) See Graphic: wc_gr002793 Wheel kit (Part No. 0162986) is a standard item on Item Number 0009545, 0009546, 0009547 and 0009548 only. Available as an option on all other models. 3.7.1 Disengage wheel kit from holding latch (a) and position wheels in “down”...

  • Page 25: Maintenance

    WP 1550 Maintenance Maintenance Periodic Maintenance Schedule 4.1.1 Engine Maintenance The chart below lists basic engine maintenance. Refer to the engine manufacturer’s Operation Manual for additional information. Daily After Every Every Every before first 2 weeks month year starting 20 hrs.
  • Page 26 Maintenance WP 1550 4.1.2 Machine Maintenance The chart below lists basic machine maintenance. Daily After Every Every Every before first 2 weeks month year starting 20 hrs. 50 hrs. 100 hrs. 300 hrs. Check external hardware. Check and adjust drive belt.

  • Page 27: Cleaning Plate

    WP 1550 Maintenance Cleaning Plate Clean plate after use to remove dirt, stones, and mud caught under the engine console. If plate is being used in a dusty area, check engine cylinder cooling fins for heavy dirt accumulation. Keep engine cylinder fins clean to prevent engine from overheating.

  • Page 28: Exciter Lubrication

    Maintenance WP 1550 Exciter Lubrication See Graphic: wpmgr006021 The exciter assembly is a self-contained, sealed unit. The bearings are lubricated using automatic transmission fluid (see Technical Data for type). Change fluid once every year or 300 hours of operation. When changing fluid, replace O-ring (a).

  • Page 29: Spark Plug

    WP 1550 Maintenance Spark Plug See Graphic: wc_gr000028 Clean or replace the spark plug as needed to ensure proper operation. Refer to your engine operator’s manual. The muffler becomes very hot during operation and remains hot for a while after stopping the engine. Do not touch the muffler while it is hot.

  • Page 30: Engine Oil

    Maintenance WP 1550 Engine Oil See Graphic: wc_gr000087 4.6.1 Drain oil while engine is still warm. Note: In the interests of environmental protection, place a plastic sheet and a container under the machine to collect any liquid which drains off. Dispose of this liquid in accordance with environmental protection legislation.

  • Page 31: Air Cleaner

    WP 1550 Maintenance Air Cleaner See Graphic: wc_gr000656 NEVER use gasoline or other types of low-flash point solvents for cleaning the air cleaner. A fire or explosion could result. WARNING NOTICE: NEVER run the engine without the air cleaner. Severe engine damage will occur.

  • Page 32: Cleaning Fuel Strainer

    Maintenance WP 1550 Cleaning Fuel Strainer See Graphic: wc_gr001093 4.8.1 To remove water and dirt, close the fuel lever and remove the fuel strainer. 4.8.2 Inspect the fuel strainer (a) for water and dirt. 4.8.3 After removing any dirt and water, wash the fuel cup with a nonflammable solvent.

  • Page 33: Troubleshooting

    WP 1550 Maintenance Troubleshooting Problem / Symptom Reason / Remedy Plate does not develop full • Engine throttle control not completely open. speed. Poor compaction. • Throttle control not adjusted correctly. • Ground too wet, plate sticking. Allow soil to dry before compacting.

  • Page 34: 4.11 Lifting Machine

    Maintenance WP 1550 4.11 Lifting Machine See Graphic: wpmgr006037 See Technical Data for the weight of the machine. To lift machine manually: 4.11.1 Stop the engine. 4.11.2 Obtain help from a partner and plan the lift. 4.11.3 Grasp the machine by its cage (a) and lifting slot (b).

  • Page 35: 4.12 Transporting Machine

    WP 1550 Maintenance 4.12 Transporting Machine See Graphic: wpmgr006055 To avoid burns or fire hazards, let engine cool before transporting machine or storing indoors. WARNING 4.12.1 Turn fuel valve to the off position and keep the engine level to prevent fuel from spilling.
  • Page 37 EC DECLARATION OF CONFORMITY EG-KONFORMITÄTSERKLÄRUNG CE-DECLARACIÓN DE CONFORMIDAD DÉCLARATION DE CONFORMITÉ DE LA CEE WACKER NEUSON MANILA, INC., DASMARIÑAS, CAVITE, PHILIPPINES WACKER NEUSON SE AUTHORIZED REPRESENTATIVE IN THE EUROPEAN UNION BEVOLLMÄCHTIGTER VERTRETER FÜR DIE EUROPÄISCHE GEMEINSCHAFT Preußenstraße 41 REPRESENTANTE AUTORIZADO EN LA UNIÓN EUROPEA 80809 München...
  • Page 38 Fax: +49 - (0)89-3 54 02-3 90 Wacker Neuson Corporation · P.O. Box 9007 · Menomonee Falls, WI 53052-9007 · Tel. : (262) 255-0500 · Fax: (262) 255-0550 · Tel. : (800) 770-0957 Wacker Asia Pacific Operations · Skyline Tower, Suite 2303, 23/F · 39 Wang Kwong Road, Kowloon Bay, Hong Kong · Tel. +852 2406 60 32 · Fax: +852 2406 60 21...
