Connector And Jumper Descriptions; Push Buttons And Leds; Jumper Settings - Texas Instruments CC3100MOD Boosterpack User Manual

2.3 Connector and jumper descriptions

2.3.1 Push buttons and LEDs

Push buttons
Reference
SW1
SW2
LEDs
Reference
D5
D1
D6

2.3.2 Jumper settings

Reference
J21
J8
TI Confidential – Strictly Private
Usage
OOB Demo
RESET
Colour Usage
RED PWR Indication
Yellow nRESET
Green nHIB
Usage
USB connector
Power selection
Comments
This is used as an input for the OOB
demo.
The use of this pin is optional. This is
used to reset the CC3100 device which
can also be accomplished using the
nHIB button. The RESET completely
erases the CC3100 RAM including the
time.
Comments
Glows when the 3.3V power is
provided to the board
This LED is used to indicate the
stated of nRESET pin. If this LED
is glowing, the device is
functional.
This LED indicates the stated of
nHIB pin. When the LED is OFF,
the device is in hibernate state.
Comments
For powering the booster pack when
mated with a Launchpad. This is
mandatory to use when using "Z"
devices. For e.g. CC3100HZ
Choose the power supply from the
EVM User's Guide
7
