5.4 Bill of materials

Qty Description
2 CAP CER 100nF 10% 10V SMD 0402 GP/HF X5R 0.5mm
14 RES C SMD 0402 0ohm 5% GP/HF
1 RES C SMD 0402 100ohm 5% GP/HF
6 RES C SMD 0402 100Kohm 1% GP/HF
2 CAP CER 100uF 20% 6.3V SMD 1210 GP/HF X5R 2.5mm
3 RES C SMD 0402 10Kohm 1% GP/HF
2 CAP CER 10nF 10% 50V SMD 0402 GP/HF X7R T=0.5mm
1 CAP CER 10pF +-0.25pF 50V SMD 0402 GP/HF NPO 0.5mm
1 CAP CER 1.0pF +-0.25pF 50V SMD 0402 GP/HF NPO T=0.55mm
1 EU-GP RES C SMD 0402 150Kohm 1% GP/HF
3 SW TACT 50mA 12V SMD ST GP/HF
2 RES C SMD 0402 1Kohm 1% GP/HF
1 CAP CER 1uF 10% 6.3V SMD 0402 GP/HF X5R 0.5mm
1 CN-GP IND WW 1uH 20% 1.4A 0.044ohm SMD GP/
1 2.4G WIFI chip antenna
1 RES C SMD 0402 2.4Mohm 5% GP/HF
1 CN-GP CAP CER 22pF 5% 50V SMD 0402 GP/HF N
1 CN-GP CAP CER 22uF 20% 6.3V SMD 0805 GP/HF
0 CN-GP CAP CER 22uF 20% 6.3V SMD 0805 GP/HF
1 CAP CER 2.2uF 10% 16V SMD 0805 GP/HF X7R T=1.25mm
0 CAP CER 2.2uF 10% 16V SMD 0805 GP/HF X7R T=1.25mm
2 RES C SMD 0402 270ohm 5% GP/HF
1 RES C SMD 0402 3.3Kohm 5% GP/HF
1 IND C 3.6nH 0.3nH 300mA 0.2ohm Q=8 SMD 0402 GP/HF
1 RES C SMD 0402 330ohm 1% GP/HF
2 RES C SMD 0402 33Kohm 1% GP/HF
1 EU-GP RES C SMD 0402 39Kohm 1% GP/HF
1 RES C SMD 0402 430Kohm 1% GP
1 BEAD C 60ohm 25% 4A 0.02ohm SMD 0603 GP/HF
1 HEADER PIN 3P 2.54mm DIP MALE ST GP
1 HEADER RF 1*1PORT D0.5/D2.0mm SMD MALE ST GP/HF
1 IC DC-DC 2.5~5.5V SMD QFN16 GP TLV62090RGTR
3 DIODE SBD 40V 2A SMD SMA GP B240A-13-F DIODES
2
1 HEADER PIN 2*3P 2.54mm DIP MALE ST GP
2 HEADER PIN 1*2P 2.54mm DIP MALE ST GP
1 LED CHIP 35mcd G 571nm 2P SMD 1.6*0.8mm GP/HF LTST-C190KG LD-0603S0
1 LED CHIP 60mcd O 605nm 2P SMD 1.6*0.8mm GP/HF LTST-C190KFLD-0603A
1 LED CHIP 45~180mcd R 624~638nm 2P SMD 1.6*0.8mm GP/HF
1 CONN MICRO USB B 5PIN 0.65mm SMD FEMALE RT GP
1 HEADER RF 1*1PORT D=0.5/1.35mm SMD FEMALE ST GP
2 MOSFET N-CH 50V 200MA SOT-23
5 CONN JUMPER 2P 2.54mm FEMALE RT GP
1 PCB 2L OSP REV.025 8PCS GP/HF 43.18*50.8mm 95.1200T00
1 Module, 802.11bgn 1x1, 17.5mmx20.5mm
0.2 CN-GP SOLDER PASTE S3X58 M500 GP/HF
0 CN-GP SOLDER PASTE S01X7C58-M500 GP/HF
TI Confidential – Strictly Private
PCB Footprint Part Number
C-0402S0 202.00008.015
C-0402S0 251.00681.025
R-0402S0 251.00004.005
r-0402s0 261.00840.025
C-1210 205.00025.005
r-0402s0 261.00839.035
C-0402S0 202.01141.015
C-0402S0 202.00035.005
C-0402S0 202.00021.005
r-0402s0 261.00013.005
SW-1BT002S1 182.00083.005
r-0402s0 261.00835.025
C-0402S0 202.00059.035
L-S3X3A 132.00816.005
ANT-S3_2X1_6-2A JSAH316M245001
R-0402S0 251.00691.005
C-0402S0 202.01137.035
C-0805 204.00611.005
C-0805 204.00621.005
C-0805 204.00625.015
C-0805 204.00625.005
251.00025.025
R-0402S0
r-0402s0 251.00027.005
l-0402s0 130.01491.005
R-0402S0 261.00040.025
R-0402S0 261.01048.005
R-0402S0 261.00868.005
R-0402S0 261.01419.005
L-0603S0 151.00402.005
CN-3X1-2_54 341.00543.005
CJ-RF-S3_1X3-3 341.00021.005
tqfn-3x3-16eshs1 029.00431.005
M-D-SMAH2_3 112.00010.005
cn-10x2-2_54c JSSSQ-110-03-G
cn-D3x2-2_54HD 341.00544.005
CN-D2X1-2_54S0 341.00391.005
123.00170.005
123.00171.005
LD-0603S0 123.00172.005
CJ-USBSUA-160M3B-L2AT 342.00757.005
CN-MM8030S0 341.00454.005
sot-23b 104.00459.005
340.00013.005
307.00587.025
LGA T77H533.00
591.00046.005
591.00056.005
Manufacturer Mfr. PN Part Reference
Murata GRM155R61A104KA01D C15 C27
R15 R22 R29 R36 R37 R38 R44 R46 R48 R65 R66 R73 R81 R82
Yageo RC0402JR-070RL
Yageo RC0402JR-07100RL R12
Yageo RC0402FR-07100KL R4 R6 R7 R75 R80 R111
MURATA GRM32ER60J107ME20L C65 C66
Yageo RC0402FR-0710KL R8 R209 R210
MURATA GRM155R71H103KA88D C3 C7
WALSIN 0402N100C500LT
C67
WALSIN 0402N1R0C500LT
C64
TA-I RM04FTN1503 R13
FOXCONN 1BT002-0120L-7H
SW1 SW2 SW3
Yageo RC0402FR-071KL R9 R20
MURATA GRM155R60J105KE19D C47
MURATA LQH3NPN1R0MM0L L1
Taiyo_Yuden AH316M245001-T ANT1
TA-I RM04JTN245 R11
MURATA GRM1555C1H220JA01D
C23
MURATA GRM21BR60J226ME39L C4
TDK C2012X5R0J226MT C4
MURATA GRM21BR71C225KA12L C17
WALSIN 0805B225K160CT C17
Yageo/Phycomp. RC0402JR-07270RL
R71 R72
TA-I RM04JTN332 R78
TAIYO HK10053N6S-T L4
Yageo/Phycomp. RC0402FR-07330RL R205
TA-I RM04FTN3302
R77 R84
TA-I RM04FTN3902 R21
WALSIN WR04X4303FTL R5
CHILISIN UPB160808T-600Y-N
FB17
CVILUX
CH31032V200 J8
FOXCONN KK23017-01-7F J2
TI TLV62090RGTR U1
DIODES B240A-13-F
D3 D4 D8
Samtec SSQ-110-03-G-D J9 J10
CVILUX CH81062V200
J4
CVILUX CH31022V202
J5 J6
LITEON LTST-C190KGKT
D6
LITEON LTST-C190KFKT
D1
LITEON LTST-C190KRKT
D5
POWERWAY SUA-160M3B-L2E-TR1
J7
MURATA MM8030-2610RJ3 J3
On Semi BSS138LT3G Q7 Q8
FOXCONN SJ2520H-A0
ZHENDING/APCB 307.00587.025 PCB
FOXCONN T77H533.00 U11
KOKI S3X58-M500
KOKI S01X7C58-M500
