SN8P2511
USER'S MANUAL
Version 1.2
SN8P2511
S
O
N
i
X
S
O
N
i
X
SONIX reserves the right to make change without further notice to any products herein to improve reliability, function or design. SONIX does not
assume any liability arising out of the application or use of any product or circuit described herein; neither does it convey any license under its patent
rights nor the rights of others. SONIX products are not designed, intended, or authorized for us as components in systems intended, for surgical
implant into the body, or other applications intended to support or sustain life, or for any other application in which the failure of the SONIX product
could create a situation where personal injury or death may occur. Should Buyer purchase or use SONIX products for any such unintended or
unauthorized application. Buyer shall indemnify and hold SONIX and its officers, employees, subsidiaries, affiliates and distributors harmless against
all claims, cost, damages, and expenses, and reasonable attorney fees arising out of, directly or indirectly, any claim of personal injury or death
associated with such unintended or unauthorized use even if such claim alleges that SONIX was negligent regarding the design or manufacture of
the part.
SONiX TECHNOLOGY CO., LTD
8
-
B
i
t
M
i
8
-
B
i
t
M
i
c
r
o
-
C
o
n
c
r
o
-
C
o
n
Page 1
8-Bit Micro-Controller
t
r
o
l
l
e
r
t
r
o
l
l
e
r
Version 1.2
SN8P2511

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SN8P2511 and is the answer not in the manual?

Questions and answers

Related Manuals for SONIX SN8P2511

Summary of Contents for SONIX SN8P2511

  • Page 1 SONIX products are not designed, intended, or authorized for us as components in systems intended, for surgical implant into the body, or other applications intended to support or sustain life, or for any other application in which the failure of the SONIX product could create a situation where personal injury or death may occur.

  • Page 2: Amendent History

    VER 1.0 Feb. 2012 First issue. VER 1.1 Apr. 2012 Add features selection table and migration section. VER 1.2 Jan. 2013 Modify 32KHz oscillator to match capacitor in external high-speed oscillator section. Version 1.2 SONiX TECHNOLOGY CO., LTD Page 2...

  • Page 3: Table Of Contents

    THE SYSTEM OPERATING VOLTAGE ..................32 LOW VOLTAGE DETECTOR (LVD) .................... 32 BROWN OUT RESET IMPROVEMENT ..................34 EXTERNAL RESET ........................35 EXTERNAL RESET CIRCUIT ....................... 35 3.9.1 Simply RC Reset Circuit ......................35 Version 1.2 SONiX TECHNOLOGY CO., LTD Page 3...
