- Page 1 FIX RAPID SELF-REPAIRING DOOR USER’S AND INSTALLER’S MANUAL v3.0 REV. 08/2022...
-
Page 2: Table Of Contents
00. CONTENT 01. SAFETY INSTRUCTIONS INDEX STANDARDS TO FOLLOW 01. SAFETY INSTRUCTIONS This product is certified in accordance with European STANDARDS TO FOLLOW Community (EC) safety standards. 02. PACKAGE INSIDE PACKAGE This product complies with Directive 2011/65/EU of the 03. AUTOMATISM European Parliament and of the Council, of 8 June 2011, on TECHNICAL SPECIFICATIONS the restriction of the use of certain hazardous substances in... - Page 3 01. SAFETY INSTRUCTIONS GENERAL WARNINGS • Children shouldn’t play with the product or opening devices to avoid the motorized door or gate from being triggered involuntarily. • This manual contains very important safety and usage information. very important. Read all instructions carefully before beginning the WARNINGS FOR TECHNICIANS installation/usage procedures and keep this manual in a safe place that it can be consulted whenever necessary.
- Page 4 01. SAFETY INSTRUCTIONS RESPONSABILITY September 2009. • Attach the permanent label for the manual release as close as possible • Supplier disclaims any liability if: to the release mechanism. • Product failure or deformation result from improper installation • Disconnect means, such as a switch or circuit breaker on the electrical use or maintenance! panel, must be provided on the product’s fixed power supply leads in •...
-
Page 5: Package
02. PACKAGE 03. AUTOMATISM INSIDE PACKAGE TECHNICAL SPECIFICATIONS The Self-Repairing Rapid Door FIX is built with its own white lacquered aluminum profiles. Motor Aluminum It is certified to IP23 protection level. cover Safe Profile MOTOR • Power Supply 230V 50/60Hz Motor •... -
Page 6: Dimensions - Normal Kit
275(OLM) 550(PM) 65(OLC) 510(PM) LVT - 66 LVT-66 The dimensions of the lateral guides and push button are the same in the Normal KIT and FIX 5 Kit. Wall Wall LEGEND Lateral Lateral OLM • Motors side clearance guide guide OLC •... -
Page 7: Dimensions - Tunnel Kit
03. AUTOMATISM 03. AUTOMATISM DIMENSIONS - TUNNEL KIT MANUAL OPENING/CLOSING To open or close the door manually, simply pull and hold down the unlock and insert the crank, to ??(OLM) 64(OLC) 275,65(OLM) 550(PM) 65(OLC) turn the screw installed at the bottom of the motor (see image). 510(PM) 335,23 •... -
Page 8: Installation
04. INSTALLATION INSTALLATION MAP 1 • 5 • 9 • 13 • Aluminum safe profile Control Board Motor unlock lever Photocell fixation plate 2 • 6 • 10 • Emergency stop 14 • Lateral Guides Safe profile Photocell 3 • 7 •... -
Page 9: Safe Profile Fixation
120mm Center-aligned safe profile FIX SAFE PROFILE Drill the holes at the marked locations, and then apply the safe profile to the wall, fixing it with dowels and screws, suitable to the installation place. -
Page 10: Lateral Guides And Control Board Fixation
8.2 Fix the tether to plate A. control board and fix it to the wall. 8.3 Fix plate C to plate B and the tether. 8.4 Tighten the 2 screws at the top of the cover. ADJUST SWITCH-LIMIT (PAGE 12) -
Page 11: Installation Tunnel Kit
Based on the holes in the support plates, mark the locations for drilling. Safe profile completely leaning against the wall and ceiling. FIX SAFE PROFILE Drill the holes at the marked locations, and then apply the safe profile to the wall, fixing it with dowels and screws. -
Page 12: Lateral Guides And Control Board Fixation
FIXING THE LATERAL GUIDE SUPPORT TUBE FIX LATERAL GUIDE 400mm For the operation of the self- Use screws to fix the lateral repairing system when applied guides to the support tubes. in tunnel, it is necessary to apply The first screw should be... -
Page 13: Limit-Switches
06. LIMIT-SWITCHES LIMIT-SWITCHES ADJUSTMENT • ADJUSTMENT • CONNECTIONS The ring 4 should activate the micro switch from below, and the ring 3 should activate the micro switch from below. CLOSE ABRIR Manually place the door in the area you want for the opening slowdown. Turn the adjusting screw 4 until the limit switch ring 4 activates the corresponding microswitch. -
Page 14: Troubleshooting
07. TROUBLESHOOTING INSTRUCTIONS FOR CONSUMERS / TECHNICIANS PROBLEM CAUSE/SOLUTION 1 • Reset 2 • Wait 15 seconds. 3 • Press OPEN and the tarpaulin will reattach to the lateral guides. • This warning comes when an object hits the 1 • Turn off the circuit breaker. tarpaulin, causing it to jump out of the lateral guides 2 •...
