Summary of Contents for Motorline professional TELICA
- Page 1 TELICA TELICA USER’S AND INSTALLER’S MANUAL V4.3 REV. 01/2024...
-
Page 2: Table Of Contents
00. CONTENT 01. SAFETY INSTRUCTIONS INDEX This product is certified in accordance with European Community (EC) safety standards. 01. SAFETY INSTRUCTIONS This product complies with Directive 2011/65/EU of the European 02. THE PACKAGE Parliament and of the Council, of 8 June 2011, on the restriction INSIDE THE PACKAGE of the use of certain hazardous substances in electrical and 03. -
Page 3: Safety Instructions
01. SAFETY INSTRUCTIONS GENERAL WARNINGS • Children shouldn’t play with the product or opening devices to avoid the motorized door or gate from being triggered involuntarily. • This manual contains very important safety and usage information. • If the power cable is damaged, it must be replaced by the Read all instructions carefully before beginning the installation/ manufacturer, after-sales service or similarly qualified personnel usage procedures and keep this manual in a safe place that it can... - Page 4 01. SAFETY INSTRUCTIONS the power supply cable. Please note that all the cables must enter conditions have been met. the control board from the bottom. • In the event of tripping of circuits breakers of fuse failure, locate • If the automatism is to be installed at a height of more than 2,5m the malfunction and solve it before resetting the circuit breaker or from the ground or other level of access, the minimum safety and replacing the fuse.
-
Page 5: The Package
02. THE PACKAGE 03. AUTOMATION INSIDE THE PACKAGE DIMENSIONS The dimensions of the TELICA automation are the following: Components on the 2 motor's package: Components on the 1 motor's package: 01 • 02 articulated motors 01 • 01 articulated motor 02a •... -
Page 6: Installation
04. INSTALLATION 04. INSTALLATION INTERIOR OPENING INSTALLATION DIMENSIONS EXTERNAL OPENING INSTALLATION DIMENSIONS When installing the automation, it is mandatory to respect the dimensions x and y, indicated in the tables. Within this area, it is possible to identify the maximum opening angle that the gate reaches in these dimensions. -
Page 7: Emergency Unlock 6A
DIMENSION B • Horizontal distance between the center of the hinge and the center of the motor shaft. Fig. 5 an obstacle. SUPPORTS INSTALLATION EXTERNAL UNLOCK The kit exemplified below is not included in the TELICA Kit. Security Fig. 9 1 • Drill holes for M8 screw anchors. CSV100... -
Page 8: Automatism Installation 7A
04. INSTALLATION 04. INSTALLATION AUTOMATISM INSTALLATION MICROS ADJUSTMENT Remove the automation's cover. To do this, loosen the two front screws, slightly tilt Fig. 15 the cover back and pull up. 1 • Place the motor on the support plate and Fig. -
Page 9: Installation Map
04. INSTALLATION INSTALLATION MAP FLASHING MOTOR LAMP ANTENNA SELECTOR EXTERIOR PHOTOCELLS JUNCTION BOX EXTERIOR INTERIOR PHOTOCELLS PHOTOCELLS GATE STOPPER LEGEND: Connection cables Fig. 23 It is important to use stoppers at the opening and closing of the gate. If not respected, It is important to use junction boxes for connections between motors, components and components of the automation may suffer efforts for which they were not prepared, and control board. -
Page 10: Motor Connections
06. COMPONENTS TEST 05. CONNECTION SCHEME 230V MOTOR 230V MOTOR To detect if the malfunction is on the control board or on the motor is, sometimes, necessary to perform tests with direct connection to a 230Vac power supply. For this, it is necessary to intercalate a capacitor on the connection in order to the automatism to work (check the type of capacitor to be used in the product manual). -
Page 11: Maintenance
07. MAINTENANCE 24V MOTOR MAINTENANCE To detect which are the components with problems in a 24Vdc TELICA automatism installation, it's some- times necessary to run a test directly to a external power supply (24Vdc battery). • CHECK SUPPORT PLATES The diagram below shows how to make this connection. -
Page 12: Troubleshooting
08. TROUBLESHOOTING INSTRUCTIONS FOR FINAL CONSUMERS INSTRUCTIONS FOR SPECIALIZED INSTALLERS Anomaly Procedure Behavior Procedure II Discovering the origin of the problem • Motor • Check that the • Still not working • Consult a qualified 1 • Open control board and check if it has 230Vac/24Vdc power supply; MOTORLINE technician.
