- Page 1 LINCE PUMA USER’S AND INSTALLER’S MANUAL v1.0 REV. 11/2024...
- Page 2 00. CONTENT 01. SAFETY INSTRUCTIONS INDEX This product is certified in accordance with European Community 01. SAFETY INSTRUCTIONS (EC) safety standards. STANDARDS TO FOLLOW This product complies with Directive 2011/65/EU of the European 02. PACKAGE Parliament and of the Council, of 8 June 2011, on the restriction of the use of certain hazardous substances in electrical and INSIDE PACKAGE electronic equipment and with Delegated Directive (EU) 2015/863...
- Page 3 01. SAFETY INSTRUCTIONS GENERAL WARNINGS • Children shouldn’t play with the product or opening devices to avoid the motorized door or gate from being triggered involuntarily. • This manual contains very important safety and usage information. • If the power cable is damaged, it must be replaced by the Read all instructions carefully before beginning the installation/ manufacturer, after-sales service or similarly qualified personnel usage procedures and keep this manual in a safe place that it can...
- Page 4 01. SAFETY INSTRUCTIONS the power supply cable. Please note that all the cables must enter conditions have been met. the control board from the bottom. • In the event of tripping of circuits breakers of fuse failure, locate • If the automatism is to be installed at a height of more than 2,5m the malfunction and solve it before resetting the circuit breaker or from the ground or other level of access, the minimum safety and replacing the fuse.
- Page 5 02. PACKAGE 03. AUTOMATION INSIDE PACKAGE TECHNICAL SPECIFICATIONS In the package you will find the following components: • Power supply of the control board 230/110Vac • Motor output voltage 24Vdc • Rated power • Nominal consumption • Opening speed 20mm/seg. •...
- Page 6 04. INSTALLATION 04. INSTALLATION HEIGHT OF THE SUPPORTS INTERIOR OPENING INSTALLATION DIMENSIONS The automation must be installed with a small inclination, to prevent water infiltration through the In the diagrams illustrated below and on the next page, the dimensions for the installation of extension arm.
- Page 7 04. INSTALLATION 04. INSTALLATION EXTERNAL OPENING INSTALLATION DIMENSIONS INSTALLATION PROCESS In the diagrams illustrated below and on the next page, the dimensions for the installation of automations are defined. Pay attention to installation dimensions mentioned on pages 5A, 5B and 6A! *A stopper must be placed at the opening (A) and another at the closing *Stopper at the...
- Page 8 04. INSTALLATION 04. INSTALLATION INSTALLATION STEPS INSTALLATION STEPS 05 • Test movement • Install the dowels removed earlier on each place with a small amount of lubricant for less friction. • Move the gate by hand to check that the gate opens and closes without any hindrance.
- Page 9 04. INSTALLATION INSTALLATION MAP • INTERIOR • JUNCTION • EXTERIOR • MOTOR • KEY • FLASHING • ANTENNA • CONTROL PHOTOCELLS PHOTOCELLS SELECTOR LAMP BOARD • EXTERIOR PHOTOCELLS LEGEND: • Connection cables It is mandatory to use stoppers when opening and closing the gate. If this is not respected, the It is important to use junction boxes for connections between motors, components and con- automation components may suffer stress for which they were not prepared, and as a result trol board.
- Page 10 05. TROUBLESHOOTING FINAL CONSUMERS INSTRUCTIONS INSTRUCTIONS FOR SPECIALIZED INSTALLERS Anomaly Procedure Behavior Procedure II Discovering the origin of the problem • Motor •Make sure you • Still not working • Consult a qualified 1 • Open control board and check if it has 230V/110V/24V power supply; doesn't work have power in the MOTORLINE technician.
- Page 11 06. MAINTENANCE MAINTENANCE CHECK MOTOR SUPPORTS CLEAN THE TUBE • Make sure that supports remain well fixed on the pillars and gate to ensure proper functioning of the equipment. • With a cloth soaked in lubricant spray, clean all the residues that accumulate in the automation tube.
- Page 12 07. COMPONENTS TEST 24V MOTOR To detect which are the components with problems in a 24V automatism installation, it's sometimes necessary to run a test directly to a external power supply (24V battery). The diagram below shows how to make this connection. NOTES: •...
