- Page 1 PÉRGOLA PÉRGOLA INSTALLER AND USER’S MANUAL v1.0 REV. 06/2019...
-
Page 2: Table Of Contents
(eg. Charger, USB cable, MOTOR, FABRIC AND CENTRAL INSTALLATION electronic material, controls, etc.) should not be disposed PERGOLA COVER INSTALLATION of as other household waste at the end of its useful life. To avoid possible harm to the environment or human health resulting from the uncontrolled disposal of waste, separate 04. -
Page 3: Safety Instructions
01. SAFETY INSTRUCTIONS GENERAL WARNINGS the motorized door or gate from being triggered involuntarily. • This manual contains very important safety and usage information. WARNINGS FOR TECHNICIANS very important. Read all instructions carefully before beginning the installation/usage procedures and keep this manual in a safe place •... - Page 4 01. SAFETY INSTRUCTIONS RESPONSABILITY • Attach the permanent label for the manual release as close as possible to the release mechanism. • Supplier disclaims any liability if: • Disconnect means, such as a switch or circuit breaker on the electrical •...
-
Page 5: Awning
PÉRGOLA TECHNICAL CHARACTERISTICS The PERGOLA awning is a simple and posh awning for sun protection, adaptable to all type of leisure On the awning you will find the following components: areas such as terraces, pool areas, outdoor dining tables, among others. -
Page 6: Installation
03. INSTALLATION FIXING BETWEEN WALLS FIXING WALL SUPPORT The screws, bushings and washers are not Identify the drill points based on the measurement of the tissue, for included in the kit. placement of the wall brackets. Drill 100mm deep holes and Ø10mm. -
Page 7: Fixing Wall And Leg Profiles
03. INSTALLATION FIXING WALL AND LEG PROFILES FIXING WALL SUPPORT Identify the drill points based on the measurement of the tissue, for placement of the wall brackets. Drill 100mm deep holes and Ø10mm. Place the metal bushings in the holes created. Position the wall and drill with the washers. -
Page 8: Fixing Leg Profiles
03. INSTALLATION FIXING LEG PROFILES ATTACH VERTICAL PROFILES The screws, bushings and washers are not Attach the vertical profiles to the shoes. Apply the included in the kit. screw with the washer and nut. ATTACH FRONT AND REAR PROFILES Attach the front and rear profiles to the vertical profiles. -
Page 9: Motor, Fabric And Central Installation
03. INSTALLATION MOTOR, FABRIC AND CENTRAL INSTALLATION TUBE SUPPORT Unscrew the bracket screws and remove the part. MOTOR SUPPORT Fit the TUB90M8 MT on the opposite side to awakened the support. MOTOR ATTACHMENT Attach the stand to the TUB90M8 MT and drop it into the projection profile. Tighten the screws. -
Page 10: Pergola Cover Installation
03. INSTALLATION PÉRGOLA COVER INSTALLATION The Pergola fabric cover is sold separately. It has a width greater than the total width of the These first two steps should be repeated on the two support rails as well as on the other fabric so that it is totally protected in its extremities. -
Page 11: Regulation
04. REGULATION LIMIT SWITCHES LIMIT SWITCHES OF OPENING AND CLOSURE The motor limit switches are preset at the factory. If you need to make any adjustments, follow the instructions in the image below. Opening Course Controls the opening stroke of the engine. -
Page 12: Troubleshooting
05. TROUBLESHOOTING FINAL CONSUMERS AND SPECIALIZED TECHNICIANS INSTRUCTIONS Problems Behavior Procedure The awning is not secure • Check the installation measures. • The screws are not suitable for the wall structure. properly on the wall. • Check that the number of screws is sufficient and that they are indicated in this manual. The awning does not remain •...
