Intermec EasyCoder 501 – User's Manual

PAPER LOAD – TEAR OFF, cont'd.

In case of an EasyCoder 501 E or 501 SA, rotate the label slack absorber 180˚ clockwise to open position (snap-lock).

Then thread the paper underneath the slack absorber and under the guide plate of the label stop sensor.

This diagram shows the path of the paper web.

Push the paper inwards as far as it will go.

In case of an EasyCoder 501 S, adjust the green guide

Turn the printhead lift knob to "Print" position.

ring so the paper is guided with a minimum of play.
