Intermec EasyCoder 501 – User's Manual

PAPER LOAD – PEEL OFF, cont'd.

In case of an EasyCoder 501 E or 501 SA, rotate the label slack absorber 180˚ clockwise to open position (snap-lock).

Then thread the label web underneath the slack absorber and under the guide plate of the label stop sensor.

In case of an EasyCoder 501 S, thread the paper under-

This diagram shows the path of the label web and the

neath the guide shaft behind the print mechanism.

backing paper.

Pull out approx. 40 cm (15") of label web and remove the

Push the label web inwards as far as it will go.

labels from the backing paper.
