Intermec EasyCoder 501 – User's Manual
PAPER LOAD – REWIND, cont'd.
10 11
Thread the labels around the rewind guide and back
Pull out approximately 40 cm (15") of labels.
under the print mechanism towards the rewind unit.
12
13
1.
2.
Wind up the end of the label web on the rewind unit and
secure it with the clip. Turn the printhead lift knob to "Print" position.
14a 14b
2.
1.
In case of an EasyCoder 501 E or 501 SA, release the
In case of an EasyCoder 501 S, adjust the green guide slack absorber (1). Adjust the green guide ring so the
ring so the paper is guided with a minimum of play. paper is guided with a minimum of play (2).
17
