Intermec EasyCoder 501 – User's Manual
RIBBON LOAD, cont'd.
5c 6
110 mm
(4.3")
#3
Press the ribbon roll onto the ribbon supply spool (1)
In case of 110 mm ribbon width, compress the unwind and thread the ribbon under the upper part of the print
bobbin and move it so it snaps into the 3:rd groove. unit. Pull out approx. 20 cm (8") of ribbon (2).
7
8
!
Be careful to thread the ribbon above the handle of the
Without releasing the ribbon, turn the printhead lift knob
label stop sensor! The ribbon must be fitted so the spools
to "Print" position so as to lock the ribbon.
rotate counter-clockwise, as illustrated above.
9 10
Press the paper core at the front end of the ribbon onto
the take-up spool. Turn the printhead lift knob to "Load" position.
21
