Summary of Contents for Clarke CML6
- Page 1 MOTORCYCLE TABLE LIFT MODEL NO: CML6 PART NO: 7610194 USER INSTRUCTIONS ORIGINAL INSTRUCTIONS GC 08/22...
-
Page 2: Specification
INTRODUCTION Thank you for purchasing this CLARKE Motorcycle Table Lift. Before attempting to use this product, please read this manual thoroughly and follow the instructions carefully. In doing so you will ensure the safety of yourself and that of others around you, and you can look forward to your purchase giving you long and satisfactory service. -
Page 3: Safety Precautions
SAFETY PRECAUTIONS 1. Ensure that the lift is in good working order. Have any damaged parts repaired or replaced immediately. Use genuine CLARKE parts only. The use of unauthorised parts may be dangerous and will invalidate the warranty. 2. Only use the lift in a suitable, well lit work area. -
Page 4: Positioning The Lift
OPERATING INSTRUCTIONS WARNING: BEFORE LIFTING, ENSURE THE SAFETY PRECAUTIONS ARE STRICTLY FOLLOWED. WARNING: BEFORE USE, ENSURE THAT THE MOTORCYCLE HAS A SUITABLE STRUCTURE AND CENTRE OF GRAVITY TO ACCOMMODATE THE LIFT SUPPORTS WITHOUT DAMAGING THE MOTORCYCLE. CAUTION: DO NOT USE THE LIFT IF IT WILL FOUL ON THE EXHAUST OR OTHER VULNERABLE PARTS. -
Page 5: Care And Maintenance
LIFTING THE MOTORCYCLE 1. Use the box wrench to raise the platform until the saddles reach the intended points of contact on the underside of the motorcycle. Adjust the position of the lift and/or sliding brackets as necessary and proceed to raise the motorcycle. -
Page 6: Component Parts
COMPONENT PARTS Description No Description Table Washer 20mm Bolt M12 x 50 Outer lifting arm Washer 12 Connecting spindle Saddle Centre spacer Adjustable plate Roller Bolt M10 x 25 Inside lifting arm Box Wrench Bearing Lifting screw Front mounting block Inside fixing spindle Circlip Locknut... -
Page 7: Declarations Of Conformity
DECLARATIONS OF CONFORMITY Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com...
