- Page 1 5 PIECE LIFTING KIT CGLK1 MODEL NO: PART NO: 7623300 OPERATION & MAINTENANCE INSTRUCTIONS ORIGINAL INSTRUCTIONS GC0920 - ISS 1...
- Page 2 INTRODUCTION Thank you for purchasing this CLARKE Lifting Kit. Before attempting to use this product, please read this manual thoroughly and follow the instructions carefully. In doing so you will ensure the safety of yourself and that of others around you, and you can look forward to your purchase giving you long and satisfactory service.
-
Page 3: Technical Specification
If in doubt do not use. Have the damaged parts replaced or consult your CLARKE dealer. 4. Make sure that the jack and stands are on a firm level base and there is no possibility of items slipping when under load. -
Page 4: Before Use
9. DO NOT try to lift more then the rated load for the jack. 10. DO NOT use the jack if an oil leak is apparent. Consult your CLARKE dealer. 11. Consult the vehicle handbook to determine the correct lifting points. - Page 5 NOTE: The jack may move slightly as the load is raised. It is important therefore, that the floor is clean and completely free from debris. 2. Position the jack so that the saddle is directly beneath the lifting point. • Consult the vehicle handbook to determine the lifting points.
-
Page 6: Maintenance
• The oil should be almost level with the bottom of the filler hole • Oil can be topped up using CLARKE Hydraulic Oil (p/n 3050830 1 litre). 3. Bleed any air from the jack as described below and replace the filler plug and cover plate. -
Page 7: Troubleshooting
If any of these remedies fail to restore your jack, consult your dealer. SPARE PARTS The following user serviceable parts are available from your CLARKE dealer, or CLARKE International Parts Department: Carrying Handle, Operating Lever, Castor Assembly. - Page 8 THE WHEEL CHOCKS Use the wheel chocks to prevent vehicle movement when a vehicle is being jacked on a level surface or parked on an incline. Length x width x height (open) 128 x 100 x 82 mm Product Weight 0.34 kg THE AXLE STANDS Minimum Height position 1...
- Page 9 ALWAYS make sure that before you work below the vehicle, a responsible person is aware in case of injury or accident. Do not use more than one pair of axle stands. Replace the warning label if it becomes unreadable. Use only on a hard, flat surface such as concrete.
-
Page 10: Lowering The Vehicle
USING THE AXLE STANDS WARNING: BEFORE USE, MAKE SURE THAT THERE IS NO DAMAGE TO ANY PART OF THE AXLE STAND. IF ANY FOUND, DO NOT USE. WARNING: ENSURE THAT THE VEHICLE/LOAD IS CAREFULLY LOCATED ON THE CENTRE OF THE SADDLE. FAILURE TO DO THIS CAN RESULT IN DAMAGE TO THE AXLE STANDS, LOSS OF SUPPORT TO THE LOAD, SERIOUS PERSONAL INJURY OR LOSS OF LIFE. -
Page 11: Declaration Of Conformity
DECLARATION OF CONFORMITY...
