Summary of Contents for Clarke STRONG-ARM CML7
- Page 1 HYDRAULIC MOTORCYCLE LIFT MODEL NO: CML7 PART NO: 7610201 OPERATION & MAINTENANCE INSTRUCTIONS ORIGINAL INSTRUCTIONS DL 1023...
-
Page 2: Specifications
INTRODUCTION Thank you for purchasing this CLARKE hydraulic motorcycle lift. Before attempting to operate this product, it is essential that you read this manual thoroughly and carefully follow all instructions given. In doing so you can look forward to the product giving you long and satisfactory service. -
Page 3: Safety Precautions
8. ALWAYS inspect the lift before use to ensure it is in good condition and replace any damaged or worn parts. 9. ALWAYS use spare parts supplied by CLARKE International. Using non- standard parts could be extremely dangerous. 10. ENSURE the operator is trained in both operational and safety aspects of using this product. -
Page 4: Assembly And Preparation
ASSEMBLY & PREPARATION Check to ensure that no damage has occurred during transit. Any damage should be reported to your CLARKE dealer immediately. Using a clean, level area, unpack the equipment, laying out the loose items as follows: • Main Lift •... - Page 5 2. Attach the front wheel clamp to the front end of the platform using the nuts, bolts and washers provided, as shown. The are 3 different bolt hole positions to choose from. 3. Slide the clamp plate into the clamp handle side of the clamp.
- Page 6 5. Attach the removable access plate over the rear access hole at the rear end of the ramp as shown. 6. Attach the lifting foot pedal to the lifting spindle as shown. Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com...
-
Page 7: Before Use
7. Attach the 4 U Bolts on to either side of the platform as shown. BEFORE USE Once unboxed and assembled, leave the lift for one hour to allow the oil to settle before purging the system. NOTE: Failure to allow sufficient time for the oil to settle could result in air remaining in the oil. - Page 8 4. Carefully and slowly pinch the oil filler plug, that is situated on the top of the piston as shown, to release any trapped air. DESCENT SPEED CONTROL SETTING NOTE: DO NOT adjust the descent speed control while a motorcycle is on the platform 1.
-
Page 9: Operation
OPERATION Always carry out a visual check before use to ensure the lift is serviceable. Never take things for granted. For safety purposes, loading the lift is essentially a two man operation. DO NOT exceed the maximum lifting capacity of 360kg (800lbs) UNDER NO CIRCUMSTANCES should you ride a motorcycle onto the lift, and on no account allow anyone to mount the... -
Page 10: Maintenance And Troubleshooting
7. With the safety bar correctly inserted, lower the table using the lowering foot lever to ensure the full weight of the table is taken by the safety bar. 8. If the rear wheel is to be removed, ensure the motorcycle rests on its centre stand and is well lashed down. -
Page 11: Troubleshooting
CLARKE dealer. 2) Tighten the piston parts GUARANTEE This CLARKE product is guaranteed against faulty manufacture for a period of 12 months from the date of purchase. Please keep your receipt as proof of purchase. This guarantee is invalid if the product is found to have been abused or tampered with in any way, or not used for the purpose for which it was intended. -
Page 12: Parts List
PARTS LIST ESCRIPTION ESCRIPTION Bolt M10x25 Bottom Frame Bolt M12x30 Nut M10 Washer 12 Bolt M8x35 Washer 10 Oil Release Link Spring Washer 10 Nut M8 Nut M10 Rear Arm Support Support Adjusting Screw Washer 20 Washer 6 Ring 20 Nut M6 Bolt M10x10 Castor Wheel... -
Page 13: Part Diagram
PART DIAGRAM Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com... - Page 14 DECLARATION OF CONFORMITY - UKCA Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com...
-
Page 15: Declaration Of Conformity (Ce)
DECLARATION OF CONFORMITY - CE Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com...
