Summary of Contents for Bodyworx JTM1500
- Page 1 BODYWORX JTM1500 TREADMILL Model No: JTM1500 WARNING THE BELT COMES PRE-LUBRICATED NO LUBRICATION REQUIRED Retain this owner’s manual for future reference. Read and follow all instructions in this owner’s manual.
-
Page 2: Table Of Contents
CONTENT PAGE WARRANTY REGISTRATION FORM IMPORTANT SAFETY INSTRUCTIONS SAFETY GUIDELINES PRODUCT OVERVIEW ASSEMBLY INSTRUCTIONS FOLDING INSTRUCTIONS GROUNDING METHODS OPERATION GUIDE 12-16 GETTING STARTED GUIDE SAFETY EXERCISE 19 -20 EXERCISE INSTRUCTIONS BELT ADJUSTMENT EXPLODED DRAWING PART LIST 23-24 ERROR CODE AND SIGNIFICANCE... -
Page 4: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS Before beginning any fitness program, you should obtain a complete physical examination from your physician. This exercise equipment is designed and built for optimum safety for home use. However, certain precautions always apply whenever you operate any exercise equipment. Be sure to read the entire manual before assembly and operation of this machine. -
Page 5: Safety Guidelines
SAFETY GUIDELINES Successful fitness training programs have one prominent feature in common...safety. Fitness training has some inherent dangers, as do all physical activities. The chance of injury can be greatly reduced or completely removed by using correct techniques, proper breathing, maintaining equipment in good working condition, and by wearing the appropriate clothing. -
Page 6: Product Overview
The main technical parameters Input supply voltage: 240V Working temperature: 0-40℃ Speed range: 0.8-14KM/H Incline range: 12 level motor incline Max. user weight: 120kg Distance display range: 0.00-99.9km Calories display range: 000-999 Time display range: 00：00-99：59 (min : sec) Heart rate range: 50-200 (time / min) Running surface: 420*1250mm Folding size: 930*710*1450mm Product size: 1660*710*1290mm... -
Page 7: Assembly Instructions
WHEN YOU OPEN THE CARTON, YOU WILL FIND THE BELOW SPARE PARTS: D17 Inner star Round Main frame 1 set C13 Safety key 1 set washer M8 8 pcs bolt M8*15 4 pcs D3 Allen wrench B18 Silicon oil 1 pc D1 Screw driver 1 pc D16 Round hex 5mm, 1 pc... - Page 8 STEP 3: According to the picture, tighten the bottom frame with bolt M8*45 (D16), M8*15 (D13), and the inner star washer (D17). Then lock the console frame with M8*15 (D13) and inner star washer (D17). D 1 3 D 1 3 D 1 6 D 1 6 D 1 7...
- Page 9 Step 5: Put on the safety key (C13) on the console. Step 6: To check if the running belt runs correctly, placing treadmill in folding position and tightening all the bolts. Then set speed under 3km/h and see if running belt runs without problem. ATTENTION: Must confirm complete assembly as the required above and lock all bolts.
-
Page 10: Folding Instructions
Lift up the machine and force to pull up until you heard "click" that made by safety casing stuck the pneumatic cylinder. Kick the safety sleeve lightly and pull down the machine at the same time as the arrow direction. Then the machine will fall down smoothly. -
Page 11: Grounding Methods
This product must be grounded. If it should malfunction or breakdown, grounding provides a path of least resistance for electric current to reduce the risk of electric shock. This product is equipped with a cord having an equipment-grounding conductor and a grounding plug. The plug must be plugged into an appropriate outlet that is properly installed and grounded in accordance with all local codes and ordinances. -
Page 12: Operation Guide
Operation Guide 1.1 WINDOW DISPLAY SPEED 1.2. START Normal start after 5 seconds countdown. 1.3. PROGRAM 1 manual mode, 12 pre-set programs, 1 body fat program, 3 countdown function and 3 users. 1.4. SAFETY LOCK FUNCTION The window shows"---" when take away the safety lock and the treadmill will stop quickly with "didi" alarm noise. - Page 13 1.5.3 “MODE” BUTTON When the treadmill is not running, press this button to choose countdown modes: “H-1”,“H-2”,“H-3”; “H-1” is the time countdown mode, “H-2” is the distance countdown mode, and “H-3” is the calorie countdown mode; press the “SPEED+/-” or “INCLINE+/-“button to adjust the data. After that, press the “START”...
- Page 14 CALORIES: 0.0 – 999 (C) SPEED: 0.8-14.0 (km/h) PULSE: 50 – 200 (BPM) INCLINE: 0 - 12 1.7 PULSE FUNCTION When the treadmill is running, hold the hand pulse about 5 seconds, it will display pulse data. The pulse data range is 50-200 times/ minute.
- Page 15 1.9 MANUAL MODEL OPERATION 1.9.1 Press start key, time count down 5 seconds, then treadmill will start to work with initial speed 1km/h. 1.9.2 Press speed +/-, you can adjust the speed. 1.9.3 Press incline+/-, you can adjust the incline. 1.9.4 Press stop, you can stop treadmill working.
- Page 16 1.12 User Program Besides 12 pre-set programs, there have 3 user-defined programs: U1, U2 and U3 Each user program has 10 segments. The user can set the desired speed and incline .Press "PROGRAM" button to choose U1 ,U2 or U3,press "MODE" button to enter setting condition, then set the time of the first segment. Press “SPEED+” and “SPEED-”...
-
Page 17: Getting Started Guide
Getting started guide PREPARE If you are around 35 years old, or have health problem, even this is your first time to do fitness exercise, please consult doctor or professional before use. Before you exercise, please stand on the side to learn how to operate, such as start, stop and speed adjustment. After that stand on the plastic deck of the treadmill board, catch hold of the handrail, start the treadmill at 1.6--3.2 km/h low speed, stand straight, look forward, try one foot on the belt and do it a few times, then stand on the belt to do exercise. -
Page 18: Safety Exercise
Please consult professional staff before do exercise. He can help recommend exercise rate/ intensity and time according to your age and health condition. When running, if you feel chest tightness or chest pain, irregular Heartbeats, short of breath, dizziness or feel unwell, please stop immediately! And consult professional before you continue to do exercise. -
Page 19: Exercise Instructions
EXERCISE INSTRUCTIONS Using your exerciser will provide you with several benefits, it will improve your physical fitness, tone muscle and in conjunction with a calorie controlled diet help you lose weight. 1. THE WARM UP PHASE This stage helps get the blood flowing around the body and the muscles working properly. It will also reduce the risk of cramp and muscle injury. - Page 20 EXERCISE INSTRUCTIONS 3. THE COOL DOWN PHASE This stage is to let your Cardio Vascular System and muscles wind down. This is a repeat of the warm up exercise e.g. reduce your tempo, continue for approximately 5 minutes. The stretching exercises should now be repeated, again remembering not to force or jerk your muscles into the stretch.
-
Page 21: Belt Adjustment
Place treadmill on a level surface. Make treadmill run at approximately 6-8 km/h, observe the running belt deviate condition. If the belt has drifted to the right, unplug the safety lock and power switch, and turn the right adjusting bolt 1/4 turn clockwise, then insert the power switch and safety lock, make the treadmill running, observe the running belt deviation condition. -
Page 23: Part List
Parts list A. Welding parts Description Description Base frame Incline frame Main frame Filter supporting frame Left upright Motor bracket Right upright Handrail bracket B. Plastic parts Description Description Console set Motor upper cover B1-1 Overlay Motor lower cover B1-2 Membrane key Side rail B1-3... - Page 24 Motor belt Inductor Power switch Filter Controller Single cord (black) 300 Handle pulse left keyboard Photoelectric Sensor Handle pulse right keyboard Incline motor D. Hardware parts Description Description Screw driver 13-15-17 Spring washer M8 Allen wrench T5 Hex round head bolt M6*45 Round hex bolt M10*30 Hex round head bolt M6*60 Round hex bolt M10*45...
-
Page 25: Error Code And Significance
Error code and significance Error Code Error Code Description Fault Processing Communication 1. Check if the computer is connected with the inverter well, or abnormal: The inverter any damages of the lines. and computer has 2. Check the inverter and change it if it is damaged. abnormal communication 3. - Page 26 BODYWORX JT1500 TREADMILL Model No: JTM1500 To register your warranty, please go to www.gpisports.com.au DISTRIBUTED EXCLUSIVELY BY 275 Wellington Road Mulgrave, VIC, 3170 Australia...
