MA32/D
Chapter 1. SAFETY INSTRUCTIONS
1.1. INSTALLATION INSTRUCTIONS
1.1. INSTALLATION INSTRUCTIONS
All devices can be installed in a 19-inch rack. Screw the devices at each of the two
Mounting holes of the mounting bracket on the front. Use Screws with a sufficiently
large head diameter and lock washers.
We recommend mounting the unit cantilevered. The use of guide rails and bearing
surfaces can affect the convection.
1.2. VENTILATION AND COOLING
Built-in and 19-inch racks must be ventilated adequately. The passively cooled devices
must not be placed directly over each other since the housing is cooled by convection.
There must be at least 1U space under and above the unit.
2021-10-20 | Rev. 3.7.5
1.1. INSTALLATION INSTRUCTIONS | 3/60
