CHANNEL INPUT
Each DSP channel has its own 16x1 input mixer which allows a summation of up to 16
different sources with individual gains.
SINGLE CHANNEL
NR
DESCRIPTION
Select a input interface or test tone (depends on your hard- and software-options).
Select channel of interface type.
Gain for the selected source channel.
Sets slected parameters.
Remove the patch in the input mixer.
Mixer output level.
If you set the last slot, a new input slot appears till the maximum of 16 slots is reached.
2021-10-20 | Rev. 3.7.5
MA32/D
Chapter 4. SOFTWARE
4.3. USER INTERFACES
4.3. USER INTERFACES | 30/60
