Amp Chip / Channel Mapping - Innosonix MAXX Series User Manual

Protection Function
Temperature
Direct Current
Short Circuit
Low Impedance

2.5.1. AMP CHIP / CHANNEL MAPPING

Every Amp Chip has two output channels. The assignment of Amp to Output channels is
in the table below.
Internal Amplifier
Amp 1
Amp 2
Amp 3
Amp 4
Amp 5
Amp 6
Amp 7
Amp 8
Amp 9
Amp 10
Amp 11
Amp 12
Amp 13
Amp 14
Amp 15
Amp 16
2021-10-20 | Rev. 3.7.5
Description
An assembly consisting of 8 channels shuts down at 85°C
heat sink temperature. The remaining 24 stay active. With a
Hysteresis of 25 ° C, i.e., at 60 ° C, the affected group turns
on again. Each MOSFET bridge on a module has a
shutdown threshold of 120 ° C. In this case, only two
channels are affected, and the other 30 remains active.
If the polarity of the signal changes not for more than a
second, the affected channel switches off and restarts
again after a few seconds.
The affected channel is switched off when the maximum
current of 15A is exceeded. Recovery time is about two
seconds.
The amplifier works unconditionally stable at low
impedance as long as the maximum current is not
exceeded.
Output Channel
24 / 29
23 / 30
22 / 31
21 / 32
17 / 28
18 / 27
19 / 26
20 / 25
5 / 16
6 / 15
7 / 14
8 / 13
4 / 9
3 / 10
2 / 11
1 / 12
Chapter 2. HARDWARE
2.5. PROTECTION CIRCUITS
Amplifier Module
1
1
1
1
2
2
2
2
3
3
3
3
4
4
4
4
2.5. PROTECTION CIRCUITS | 7/60
MA32/D
