IMC Networks Technical Support
Tel: (949) 465-3000 or (800) 624-1070 (in the U.S. and Canada);
+32-16-550880 (Europe)
Fax: (949) 465-3020
E-Mail: techsupport@imcnetworks.com
Web:
www.imcnetworks.com
Specifications
Environmental:
Operating Temperature: -31° F to 176° F (-35° C to 80° C)
Storage Temperature: -67° F to 257° F (-55° C to 125° C)
Humidity: 5 to 95% (non-condensing)
DC Input Specifications:
Input voltage: 35 to 75 VDC
Input Current: 500 mA MAX
iMcV Slot Current Source Capability: 2A@+5VDC
Dimensions:
1.45"H x 4.75"W x 7.30"D (3.7 cm H x 12.1 cm W x 18.6 cm D)
Heat Generation:
4 BTU/hr. maximum
6
