Specifications - Icom IC-Q7A Instruction Manual

13

SPECIFICATIONS

D General
• Frequency coverage
U.S.A. Transmit
Receive
Europe Transmit
Receive
Italy Transmit
Receive
Asia Transmit
Receive
Australia Transmit
Receive
U.S.A.-1 Transmit
Receive
• Mode
• No. of memory channels
• Usable temp. range
• Tuning steps
• Frequency stability
• Power supply requirement : 2 AA(R6) Ni-Cd or alkaline
36
: (unit: MHz)
144–148, 440–450
30–823.995, 849–868.995,
894–1309.995*
144–146, 430–440
30–1309.995*
144–148, 430–440
30–1309.995*
144–148, 430–440
30–1309.995*
144–148, 430–440
30–1309.995*
144–148, 440–450
30–1309.995*
*Specifications guaranteed 30–1300 MHz.
: FM, AM*, WFM*
*Receive only.
: 200
: –10°C to +60°C;
+14°F to +140°F
: 5, 6.25, 10, 12.5, 15, 20, 25,
30, 50 and 100 kHz
: ±6 ppm (–10°C to +60°C)
cells (negative ground)
• Current drain (VHF/UHF; at 3.0 V DC):
Tx max. power
Rx rated audio
standby
power saved
• Antenna connector
• Dimensions
(projections not included)
• Weight
• MIC/SP connector
D Transmitter
• Modulation system
• Output power
(at 3.0 V DC)
• Spurious emissions
Europe and Italy versions
Less than –60 dB (less than 1 GHz)
Less than –50 dB (greater than 1 GHz*)
Other versions
Less than –40 dB
* According to ETS 300 684 8.1.3 Limits: antenna port in
transmitter-active mode.
• Max. frequency deviation
440 mA/380 mA (typical)
170 mA (typical)
95 mA (typical)
38 mA (typical)
: SMA (50 )
: 58(W) 86(H) 27(D) mm;
9 3 1
2 ⁄ (W) 3 ⁄ (H) 1 ⁄ (D) in
32 8 16
: 170 g; 6 oz
(w/antenna and battery)
1
: 4-conductor 3.5 (d) mm ( ⁄
8
2 k /8
: Variable reactance
: 350 mW typical (VHF)
300 mW typical (UHF)
:
: ±5 kHz
˝);
