1 Overview:

The TurboX C610 Open Kit is a cost-effective solution to evaluate the
performance and build the prototype of the smart cameras and intelligent IoT
devices quickly. The Open Kit features rich interfaces, including USB Type A,
HDMI in, Ethernet, and camera mezzanine-board expansions enabling the Kit
"open" for building camera-based devices, including panorama, smart camera
and video conference camera. The Open Kit supports Linux(Q2,2020) and
Android(Q4,2020) operating system, combining powerful artificial intelligence
and machine learning to address increasing demand for smart cities, commercial
and enterprise, homes and vehicles applications.
Turbox C610 Open Kit Specification:
Category
SOM on board
Vertical Mezzanine Board (Camera board)
Display Interfaces
Audio Interfaces
General Interfaces on Mother Board
Rev. 1.0 MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION
Description
TurboX C610 SOM
Vertical A: Panorama - 2 x IMX577
Vertical B: Smart Security - 1 x IMX347 / 1 x IMX334
(3x Optical Zooming)
Vertical C: Conference: - 1 x IMX415 + 1 x HDMI IN
1 x DP; 1 x 5.0" TFT-LCD;
1 x 3.5mm headset
6 x Digital Mics(From External Codec)
2 x Speaker out (From Codec)
1 x USB 3.1 Type C
1 x USB 2.0 Type A
1 x Micro USB(For Debug)
1 x SD card;
